Brand: Panduit
|
SKU:
1018726
Panduit GB4N0024TPI-1 | Grounding Busbars | UPC - 07498311051
Regular price
$784.03
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit GB4N0024TPI-1 | Grounding Busbars | UPC - 07498311051
Regular price
$784.03
Unit price
Description
Description
Panduit Grounding Busbar, 4 in Bar Width, 36 in Bar Length, 1/4 in Bar Height, 600 VAC, 24 Mounting Hole Quantity, Flat Construction, Copper, Tin Plated
Features + Benefits
- Available with different hole pattern spacing including NEMA, BICSI and 1 in
- Made of high conductivity copper and tin plated to inhibit corrosion
- Pre-assembled with brackets and insulators attached for quick installation
Panduit GB4N0024TPI-1 Key Specs
| Sub Brand | StructuredGround |
| Material | Copper |
| Overall Length (In.) | 36 |
| Overall Length (mm) | 914.4 |
| Overall Width (In.) | 4 |
| Overall Width (mm) | 101.6 |
| Overall Height (In.) | 2.75 |
| Overall Height (mm) | 69.9 |
| Stud Hole Size (In.) | 0.53 |
| Stud Hole Size (mm) | 13.46 |
| Finish/Coating | Tin-Plated |
| Overall Thickness (In.) | 0.25 |
| Overall Thickness (mm) | 6.4 |
| Standards Met | BICSI/TIA-607-C, NEMA Hole Pattern, cULus |
| Application | Telecom/Data Center |
| Product Type | Grounding Busbars |
| Part Features | Available with different hole pattern spacing including NEMA, BICSI and 1 inch, Made of high conductivity copper and tin-plated to inhibit corrosion, Pre-assembled with brackets and insulators attached for quick installation |
Panduit GB4N0024TPI-1 Data Sheets
| Part Drawings | Part Drawing - PDF - NEMA Busbars - GB4N | Download and View |
| Catalog Cut Sheets | Catalog Cut Sheet - GB4N0007TPI-1 Product Page | Download and View |
| Catalog Cut Sheets | Catalog Cut Sheet - GB4N0007TPI-1 Product Page | Download and View |
| Flyers | Telecommunications Bonding 5 Steps: D-GRFL02 | Download and View |
| Flyers | Telecommunications Bonding 5 Steps: D-GRFL03 AUS | Download and View |
| Videos | 5 Steps to Implementing a Grounding and Bonding System Video | Download and View |
