Panduit GCC6X6250-1/0 | Structured Ground Cross Con, Copper, 1/2-5/...
Description
Description
Compatible with 6" x 6" patch panels, our grounding connector ensures reliable electrical grounding with high-strength, weather-resistant design, ideal for outdoor power distribution systems.
Grounding cross connector for #2 SOL - 250 kcmil (35 - 120mm) and #6 SOL - 1/0 STR AWG (16 - 50mm) wire size.
Panduit StructuredGround Grounding Cross Connector, Type GCC, 2 AWG Solid to 250 kcmil, 6 AWG Solid to 1/0 AWG Stranded Maximum Run/Tap, 1/2 to 5/8 in Rod, Copper, Black, 1 in L x 1.06 in W x 2.12 in H
Panduit - GCC6X6250-1/0 - Features
- Only a single die required to crimp each element, which speeds installation and reduces costs
- Wide range taking ability and multi-conductor design provide flexibility with a minimum number of parts, allowing for conductor to conductor, conductor to rebar and conductor to ground rod applications
- Designed for the enhanced crimp process using patent pending technology meets IEEE 837 2002
- Slotted design allows quick and easy assembly of conductor to connector using Panduit cable ties included
- Pre-applied conductive antioxidant compound ensures a high quality mechanical and electrical bond, speeding installation
- Color coded and marked with Panduit die index numbers for proper crimp die selection
Specifications
Specifications
Panduit - GCC6X6250-1/0 - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | GCC6X6250-1/0 |
| Connection Type | Compression |
| Material Rating | Copper |
| UNSPSC Code | 39121400 |
| Sub Brand | StructuredGround |
| Connector Type | Cross Connector |
| Material | Copper |
| Material Properties | High Conductivity |
| Overall Length (In.) | 1.06 |
| Overall Length (mm) | 26.9 |
| Overall Width (In.) | 1 |
| Overall Width (mm) | 25.4 |
| Overall Height (In.) | 2.12 |
| Overall Height (mm) | 53.3 |
| Maximum Copper Conductor Size (AWG STR) | 1/0 |
| Maximum Copper Conductor Size (kcmil) | 250 |
| Minimum Copper Conductor Size (AWG SOL) | 2 |
| Minimum Copper Conductor Size (kcmil) | 250 |
| Maximum Ground Rod Size (In.) | 5/8 |
| Maximum Ground Rod Size (mm) | 15.87 |
| Minimum Ground Rod Size (In.) | 1/2 |
| Minimum Ground Rod Size (mm) | 12.7 |
| Maximum Rebar Size (AWG) | 4 |
| Maximum Rebar Size (In.) | 1/2 |
| Maximum Rebar Size (mm) | 12.7 |
| UPC | 07498300947 |
Panduit - GCC6X6250-1/0 - Videos
| Panduit GCC6X6250-1/0 Video 1 | Click to View |
|---|---|
| Panduit GCC6X6250-1/0 Video 2 | Click to View |
