Panduit GCE500-1/0 | Structured Ground E-Tap Grounding Connector
Regular price
$48.42
Unit price
Brand: Panduit
|
SKU:
PAN-GCE500-1/0
Regular price
$48.42
Unit price
Description
Description
Panduit GCE500-1/0 | StructuredGround E-Tap Grounding Connector
Simplify installation with our grounding connector. Designed for E-style patch panels, it offers flexible, efficient, reliable connections for various grounding applications.
Panduit StructuredGround Grounding Connector, Type GCE, 250 to 500 kcmil, 6 AWG Solid to 1/0 AWG Stranded Maximum Run/Tap, 1/2 to 3/4 in Rod, Copper, Blue, 1 in L x 1.36 in W x 2.64 in H
Panduit - GCE500-1/0 - Features
- Wide range taking ability and multi-conductor design provide flexibility with a minimum number of parts, allowing for conductor to conductor, conductor to rebar and conductor to ground rod applications
- Slotted design allows quick and easy assembly of conductor to connector using Panduit cable ties included
- Pre-applied conductive antioxidant compound ensures a high quality mechanical and electrical bond, speeding installation
- Color coded and marked with Panduit die index numbers for proper crimp die selection
Specifications
Specifications
Panduit - GCE500-1/0 - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | GCE500-1/0 |
| Sub Brand | StructuredGround |
| Connector Type | E-Style Connector |
| Material | Copper |
| Material Properties | High Conductivity |
| Overall Length (In.) | 1 |
| Overall Length (mm) | 25.4 |
| Overall Width (In.) | 1.36 |
| Overall Width (mm) | 34.5 |
| Overall Height (In.) | 2.64 |
| Overall Height (mm) | 67 |
| Maximum Copper Conductor Size (kcmil) | 500 |
| Minimum Copper Conductor Size (kcmil) | 250 |
| Maximum Ground Rod Size (In.) | 3/4 |
| Maximum Ground Rod Size (mm) | 19.05 |
| Minimum Ground Rod Size (In.) | 1/2 |
| Minimum Ground Rod Size (mm) | 12.7 |
| Maximum Rebar Size (In.) | 3/4 |
| Maximum Rebar Size (mm) | 19.05 |
| Minimum Rebar Size (In.) | 5/8 |
| Minimum Rebar Size (mm) | 15.87 |
| Maximum Tap Size (AWG STR) | 1/0 |
| UPC | 07498300957 |
Panduit - GCE500-1/0 - Videos
| Panduit GCE500-1/0 Video 1 | Click to View |
|---|---|
| Panduit GCE500-1/0 Video 2 | Click to View |
