Panduit H000X034H1C P1 Cassette, Continuous Heatshrink Tubing, Mil ...
Description
Description
The H000X034H1C Military-Grade Polyolefin Continuous Heat-Shrink Label Cassette can be cut-to-length and contains an integrated memory device for automatic formatting, recall of last legend used, and the number of labels remaining in the cassette. Compatible with Easy-Mark Plus Labeling Software. For use with LS8E and LS8EQ printers. Shrink ratio 3:1. 0.34" x 8' (8.6 mm x 2.4 m) Cable diameter 0.06" - 0.19" (1.5 mm - 4.8 mm) Color White. 1 cassette
Panduit - H000X034H1C - Features
- White, 3/16"; diameter heat shrinkable polyolefin, 18 - 12 AWG.
- Fast loading P1(TM) Label Cassette includes both label material and ribbon to make changing labels easy
- Meets print performance requirements of MIL-M-81531 and MIL-STD-202F Method 215A, Solution A, C, and D
- Meets UL Standard 224 for flammability
- Shrink ratio 3:1
- Non-adhesive flattened heat shrinkable polyolefin for wire/cable identification
Specifications
Specifications
Panduit - H000X034H1C - Product Categories
- Signs, Labels & Identification
- Portable Printer Labels & Cassettes
Panduit - H000X034H1C - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | H000X034H1C |
| Item Description | P1 Heat Shrink Label |
| Note | For use with LS8E and LS8EQ printers |
| Product Type | Heat Shrink Label |
| Color | White |
| Compatible Wire Gauge (AWG) | 18-12 |
| Material | Polyolefin |
| Resistance Properties | Military Grade |
| Standards Met | MIL-M-81531 and MIL-STD-202G Method 215K, Solution A, C, and D. UL Standard 224 for flammability. |
| Sub Brand | P1 |
| Minimum Cable Diameter (In.) | 0.06 |
| Minimum Cable Diameter (mm) | 1.5 |
| Maximum Cable Diameter (In.) | 0.19 |
| Maximum Cable Diameter (mm) | 4.8 |
| Label Height (In.) | 0.34 |
| Label Height (mm) | 8.6 |
| Roll Length (ft.) | 8 |
| Roll Length (m) | 2.4 |
| Minimum Operating Temperature (°C) | -55 |
| Minimum Operating Temperature (°F) | -67 |
| Maximum Operating Temperature (°C) | 135 |
| Maximum Operating Temperature (°F) | 275 |
| Label Application | Cable & Wire Marking |
| Overall Width (In.) | 0.34 |
| Overall Width (mm) | 8.6 |
Panduit - H000X034H1C - Package Information
| UPC | 07498366369 |
|---|---|
| Standard Package Quantity | 1 |
| Standard Package Volume (cf) | 0.0931 |
| Standard. Ctn. Quantity | 10 |
| Standard. Ctn. Volume (cf) | 0.9309 |
