Panduit H000X064H2C | P1 Heat Shrink Label
Description
Description
Protect critical wires and cables with our military-grade polyolefin continuous heat-shrink label cassette. It offers reliable protection and clear identification in demanding environments.
The portable printer continuous heat shrink labels in yellow are made of military-grade polyolefin. They measure 0.38" (9.7mm) diameter, 6’ (1.8m) length, and 0.64" (16.3mm) width and have a wire range of 12"6 AWG. The fast-loading P1 label cassette in cludes both label material and ribbon for easy label changing.
Panduit Heat Shrink Label Cassette, Continuous, 72 in Length, 0.64 in Width, 12 to 6 AWG Wire, Yellow Marker, Polyolefin, -67 to 275 deg F
Panduit - H000X064H2C - Features
- P1 Label cassette contains an integrated memory device for automatic formatting, recall of last legend used and number of labels remaining in the cassette
- Fast loading label cassette includes both label material and ribbon to make changing labels easy
- Each cassette contains a continuous roll of non-adhesive flattened polyolefin that can be cut to length
- Durable flattened polyolefin, high quality heat shrink wire and cable labels
- 3:1 shrink ratio
- Made of military grade polyolefin
- For PanTher LS8E/Cougar LS9 hand-held thermal transfer printer
Specifications
Specifications
Panduit - H000X064H2C - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | H000X064H2C |
| Type | Labels |
| UNSPSC Code | 55120000 |
| Note | For use with LS8E and LS8EQ printers |
| Product Type | Heat Shrink Label |
| Color | Yellow |
| Compatible Wire Gauge (AWG) | 12-6 |
| Material | Polyolefin |
| Resistance Properties | Military Grade |
| Standards Met | MIL-M-81531 and MIL-STD-202G Method 215K, Solution A, C, and D. UL Standard 224 for flammability. |
| Sub Brand | P1 |
| Maximum Cable Diameter (In.) | 0.38 |
| Maximum Cable Diameter (mm) | 9.7 |
| Minimum Cable Diameter (In.) | 0.13 |
| Minimum Cable Diameter (mm) | 3.3 |
| Roll Length (ft.) | 6 |
| Roll Length (m) | 1.8 |
| Label Height (In.) | 0.64 |
| Label Height (mm) | 16.3 |
| Overall Width (In.) | 0.64 |
| Overall Width (mm) | 16.3 |
| Label Application | Cable & Wire Marking |
| Minimum Operating Temperature (°C) | -55 |
| Minimum Operating Temperature (°F) | -67 |
| UPC | 07498331926 |
