Brand: Panduit
|
SKU:
10045709
Panduit H100X025H2T-2-B | Military-Grade Two-Sided Thermal Transfer Heat Shrink Label
Regular price
$1,556.43
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit H100X025H2T-2-B | Military-Grade Two-Sided Thermal Transfer...
Regular price
$1,556.43
Unit price
Description
Description
Panduit H100X025H2T-2-B | Military-Grade Two-Sided Thermal Transfer Heat Shrink Label
Panduit Pan-Code Heat Shrink Label, Double Sided Thermal Transfer, 1/4 in Length, 1 in W, 22 to 18 AWG Wire, Yellow Marker, Polyolefin, -67 to 275 deg F
Our military-grade, two-sided label meets stringent military and industry standards, and allows for more comprehensive and detailed information with the double printing space.
Panduit - H100X025H2T-2-B - Features
- Permanent, 1-piece, heat shrink sleeve designed to provide clear, durable identification of wires and cables
- Can be printed on both sides for improved visibility
- Tested as an identification marker for use in (Class 1E) harsh environments
- Use thermal transfer hybrid ribbon
- Heat shrink labels are mounted on a plastic carrier and offer crisp, clear legends with superior readability for quick and easy label production in all label formats, including thermal transfer and dot matrix printable
- 3:1 shrink ratio
- Made of flattened military grade polyolefin
Specifications
Specifications
Panduit - H100X025H2T-2-B - Specifications
| Type | Labels |
|---|---|
| UNSPSC Code | 55120000 |
| Label Dimensions (In.) | 1W x 0.25H |
| Product Type | Heat Shrink Label |
| Color | Yellow |
| Compatible Wire Gauge (AWG) | 18 |
| Diameter (In.) | 0.13 |
| Diameter (mm) | 3.3 |
| Material | Polyolefin |
| Flammability Rating | VW-1 |
| Number of Labels per Row | 2 |
| Number of Sides | 1 |
| Maximum Operating Temperature (°C) | 135 |
| Maximum Operating Temperature (°F) | 275 |
| Minimum Operating Temperature (°C) | -55 |
| Minimum Operating Temperature (°F) | -67 |
| Overall Length (In.) | 0 |
| Overall Length (mm) | 0 |
| Overall Width (In.) | 1 |
| Overall Width (mm) | 25.4 |
| Overall Height (In.) | 0.25 |
| Overall Height (mm) | 6.4 |
| Resistance Properties | Military Grade |
| UPC | 07498319490 |
Panduit - H100X025H2T-2-B - Package Information
| UPC | 07498319490 |
|---|---|
| Standard Packaging Quantity | 1 |
| Standard Packaging Volume (cf) | 0.3402 |
| Standard Ctn. Quantity | 0 |
| Standard Ctn. Volume (cf) | 0.0000 |
