Brand: Panduit
|
SKU:
H100X064H1C
Panduit H100X064H1C | Heat Shrink Wire/Cable Label | UPC - 07498332302
Regular price
$151.25
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit H100X064H1C | Heat Shrink Wire/Cable Label | UPC - 07498332302
Regular price
$151.25
Unit price
Description
Description
Panduit P1 Heat Shrink Label Cassette, Die-Cut Military Grade, 1 in Length, 0.64 in Width, 12 to 6 AWG Wire, White Marker, Polyolefin, -67 to 275 deg F
Features + Benefits
- P1 Label Cassette contains an integrated memory device for automatic formatting, recall of last legend used, and number of labels remaining in the cassette
- Fast loading label cassette includes both label material and ribbon to make changing labels easy
- Each cassette contains a roll of die-cut non-adhesive flattened polyolefin
- Shrink ratio 3:1
- Use with PanTher LS8E or Cougar LS9 hand-held thermal transfer printers
- There are 75 labels per cassette
Panduit H100X064H1C | Heat Shrink Wire/Cable Label | UPC - 07498332302 Key Specs
| Note | For use with LS8E and LS8EQ printers |
| Product Type | Heat Shrink Wire/Cable Label |
| Color | White |
| Compatible Wire Gauge (AWG) | 12-6 |
| Material | Polyolefin |
| Number of Labels | 75 |
| Resistance Properties | Military Grade |
| Standards Met | MIL-M-81531 and MIL-STD-202G Method 215K, Solution A, C, and D. UL Standard 224 for flammability. |
| Sub Brand | P1 |
| Minimum Cable Diameter (In.) | 0.13 |
| Minimum Cable Diameter (mm) | 3.3 |
| Maximum Cable Diameter (In.) | 0.38 |
| Maximum Cable Diameter (mm) | 9.7 |
| Label Height (In.) | 0.64 |
| Label Height (mm) | 16.3 |
| Label Width (In.) | 1 |
| Label Width (mm) | 25.4 |
| Minimum Operating Temperature (°C) | -55 |
| Minimum Operating Temperature (°F) | -67 |
| Maximum Operating Temperature (°C) | 135 |
Panduit H100X064H1C | Heat Shrink Wire/Cable Label | UPC - 07498332302 Data Sheets
| Catalog Cut Sheets | Mil Grade Heat Shrink Cassettes Catalog Page | Download and View |
| Part Drawings | Mil Grade Heat Shrink Part Drawing | Download and View |
| Product Bulletins | PanTher LS8E and LS8EQ Hand-Held Thermal Transfer Printers | Download and View |
Panduit H100X064H1C | Heat Shrink Wire/Cable Label | UPC - 07498332302 Environmental Information
| Panduit's RoHS Statement | Download and View |
