Panduit H100X084HFT-2 | 2-Sided LSZH HS Lbl, WH, .5" dia, 1000/roll
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit H100X084HFT-2 | 2-Sided LSZH HS Lbl, WH, .5" dia, 1000...
Description
Description
Upgrade your labeling with our halogen-free two-sided heat shrink label. Its durability is perfect for harsh environments.
The thermal transfer halogen free heat-shrink label in white is 2-sided with a 1/2" (12.7mm) diameter and made of flame retardant, low smoke cross-linked polyolefin. It is 1" (25.4mm) wide and .84" (21.3mm) high. The heat-shrink sleeve is designed to p rovide a clear, reliable, and durable way to identify wires and cables. The sleeve has 2 label(s) per row and 1000 labels per roll. Heat-shrink labels are mounted on a plastic carrier and offer crisp, clear legends with superior readability for quick a nd easy label production in all label formats, including thermal transfer and dot matrix printable.
Panduit Heat Shrink Label, 2-Sided Thermal Transfer, 0.84 in Length, 1 in Width, 8 to 1 AWG Wire, White Marker, Polyolefin, -22 to 221 deg F
Panduit - H100X084HFT-2 - Features
- Permanent, 1-piece, heat shrink sleeve designed to provide clear, durable identification of wires and cables
- Can be printed on both sides for improved visibility
- Use thermal transfer hybrid ribbon
- Made of flame-retardant, low smoke cross linked polyolefin
- Heat shrink labels are mounted on a plastic carrier and offer crisp, clear legends with superior readability for quick and easy label production in all label formats, including thermal transfer and dot matrix printable
- 2:1 shrink ratio
- Made low smoke halogen-free cross linked polyolefin
Specifications
Specifications
Panduit - H100X084HFT-2 - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | H100X084HFT-2 |
| Type | Labels |
| UNSPSC Code | 55120000 |
| Note | For use with TDP printers |
| Label Dimensions (In.) | 1W x 0.84H |
| Product Type | Heat Shrink Label |
| Color | White |
| Compatible Wire Gauge (AWG) | 18 |
| Diameter (In.) | 0.5 |
| Diameter (mm) | 12.7 |
| Material | Polyolefin |
| Flammability Rating | VW-1 |
| Number of Labels | 1000 |
| Number of Labels per Row | 2 |
| Number of Sides | 2 |
| Maximum Operating Temperature (°C) | 105 |
| Maximum Operating Temperature (°F) | 221 |
| Minimum Operating Temperature (°C) | -30 |
| Minimum Operating Temperature (°F) | -22 |
| Overall Width (In.) | 1 |
| Overall Width (mm) | 25.4 |
| Overall Height (In.) | 0.84 |
| Overall Height (mm) | 21.3 |
| Standards Met | (1) Material is RoHS compliant (European Union directive 2002/95/EC)(2) Satisfies BS6853; 1999 Vehicle Category 1a(3) Meet SAE-AS5942, MIL-STD-883F Method 2015.13, MIL-STD-202G Method 215K(4) RoHS Compliant |
| UPC | 07498341082 |
