Panduit H200X034H2T-2-B | Pan-Code Heat Shrink Label
Description
Description
Our military-grade, two-sided label meets stringent military and industry standards, and allows for more comprehensive and detailed information with the double printing space.
Panduit is a global leader in reliable and innovative solutions for identification and safety. Products are engineered for a wide variety of industries and applications -including electrical, electronics, industrial and network. Panduit offers a complete, leading edge line of labeling software, high performance label materials (all RoHS compliant) and printers that provide enhanced productivity, dependability and value to all infrastructure labeling requirements.
Panduit Pan-Code Heat Shrink Label, Double Sided Military Grade Thermal Transfer, 0.34 in Length, 2 in W, 18 to 12 AWG Wire, Yellow Marker, Polyolefin, -67 to 275 deg F
Panduit - H200X034H2T-2-B - Features
- Labels offer crisp, clear legends with superior legibility
- Will meet MIL-M-81531, MIL-STD202F and MIL-STD-883E when printed with RMH4BL or RHH4BL-S ribbons
- Shrink ratio 3:1
- Pre-cut flattened polyolefin is both thermal transfer and dot matrix printable and supplied roll mounted on plastic carrier
- Panduit labeling software packages include all label formats for quick and easy label production
Specifications
Specifications
Panduit - H200X034H2T-2-B - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | H200X034H2T-2-B |
| UNSPSC Code | 55120000 |
| Label Dimensions (In.) | 2W x 0.34H |
| Product Type | Heat Shrink Label |
| Color | Yellow |
| Compatible Wire Gauge (AWG) | 18 |
| Diameter (In.) | 0.19 |
| Diameter (mm) | 4.7 |
| Material | Polyolefin |
| Flammability Rating | VW-1 |
| Number of Labels per Row | 1 |
| Number of Sides | 1 |
| Maximum Operating Temperature (°C) | 135 |
| Maximum Operating Temperature (°F) | 275 |
| Minimum Operating Temperature (°C) | -55 |
| Minimum Operating Temperature (°F) | -67 |
| Overall Length (In.) | 0 |
| Overall Length (mm) | 0 |
| Overall Width (In.) | 2 |
| Overall Width (mm) | 50.8 |
| Overall Height (In.) | 0.34 |
| Overall Height (mm) | 8.6 |
| Resistance Properties | Military Grade |
| UPC | 07498319317 |
