Panduit H200X044H1T-2-B | Heatshrink, 2 side, PO, White, Mil Grade,...
Description
Description
Our military-grade, two-sided label meets stringent military and industry standards, and allows for more comprehensive and detailed information with the double printing space.
The H200X044H1T-2-B Thermal Transfer Halogen-Free Heat-Shrink Label is 2-sided and made of flame retardant, low smoke cross-linked polyolefin. The heat-shrink sleeve is designed to provide a clear, reliable, and durable way to identify wires and cables . The heat-shrink labels are mounted on a plastic carrier and offer crisp, clear legends with superior readability. Polyolefin. 2" x 0.44" (50.8 mm x 11.2 mm). 0.25" (6.3 mm) diameter. Color White. 2500 per roll.
Panduit Heat Shrink Label, 2-Sided Thermal Transfer, 0.44 in Length, 2 in Width, 16 to 10 AWG Wire, White Marker, Polyolefin, -67 to 275 deg F
Panduit - H200X044H1T-2-B - Features
- Permanent, 1-piece, heat shrink sleeve designed to provide clear, durable identification of wires and cables
- Can be printed on both sides for improved visibility
- Tested as an identification marker for use in (Class 1E) harsh environments
- Use thermal transfer hybrid ribbon
- Heat shrink labels are mounted on a plastic carrier and offer crisp, clear legends with superior readability for quick and easy label production in all label formats, including thermal transfer and dot matrix printable
- 3:1 shrink ratio
- Made of flattened military grade polyolefin
Specifications
Specifications
Panduit - H200X044H1T-2-B - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | H200X044H1T-2-B |
| UNSPSC Code | 55120000 |
| Label Dimensions (In.) | 2W x 0.44H |
| Product Type | Heat Shrink Label |
| Color | White |
| Compatible Wire Gauge (AWG) | 16-10 |
| Diameter (In.) | 0.25 |
| Diameter (mm) | 6.4 |
| Material | Polyolefin |
| Flammability Rating | VW-1 |
| Number of Labels | 2500 |
| Number of Labels per Row | 1 |
| Number of Sides | 2 |
| Maximum Operating Temperature (°C) | 135 |
| Maximum Operating Temperature (°F) | 275 |
| Minimum Operating Temperature (°C) | -55 |
| Minimum Operating Temperature (°F) | -67 |
| Overall Width (In.) | 2 |
| Overall Width (mm) | 50.8 |
| Overall Height (In.) | 0.44 |
| Overall Height (mm) | 11.2 |
| Resistance Properties | Military Grade |
| Standards Met | Meets UL Standard 224 for flammability and AMS-DTL-23053/5C (Class 1 and Class 3). Meets SAE-AS81531, MIL-STD-883F Method 2015.13, Solutions A, B, and D, and D202F, and MIL-STD-202G Method 215K, Solutions A, C, and D when printed with resin or hybrid thermal transfer ribbons. RoHS Compliant. |
| UPC | 07498319503 |
