Brand: Panduit
|
SKU:
10045138
Panduit HST1.5-9-XY | Heat Shrink | UPC - 07498310738
Regular price
$215.76
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit HST1.5-9-XY | Heat Shrink | UPC - 07498310738
Regular price
$215.76
Unit price
Description
Description
Panduit Wet-Shrink Heat Shrink Tubing, Adhesive Lined Standard, Series: HST, 600 VAC, 1/2 in Inner Dia Recovered, Thick Wall, 0.16 in Wall Thickness Recovered, 3/0 AWG to 400 kcmil Wire, 3:1 Shrink, 9 in Length, -67 to 230 deg F, 248 deg F Shrink, Polyolefin, Black
Features + Benefits
- Adhesive lined inner wall shall seal and protect against moisture
- The heat shrink tube shall be suitable for direct burial according to UL 486D
- Flame-retardant outer wall
- VW-1 flammability rating
Panduit Panduit HST1.5-9-XY | Heat Shrink | UPC - 07498310738 Key Specs
| Note | HST1.5-9-XY replaces HST1.5-9-X |
| Product Type | Heat Shrink |
| Color | Black |
| Material | Highly Flame Retardant Adhesive Lined Cross-Linked Polyolefin |
| Maximum Operating Temperature (°C) | 110 |
| Maximum Operating Temperature (°F) | 230 |
| Minimum Operating Temperature (°C) | -55 |
| Minimum Operating Temperature (°F) | -67 |
| Nominal Recovered Wall Thickness (In.) | 0.16 |
| Nominal Recovered Wall Thickness (mm) | 4.1 |
| Sub Brand | Wet-Shrink |
| Overall Length (In.) | 9 |
| Overall Length (ft.) | 0.72 |
| Overall Length (m) | 0.2 |
| Overall Length (mm) | 228.6 |
| Shrink Ratio | 3:1 |
| Shrink Temperature (°C) | 120 |
| Shrink Temperature (°F) | 248 |
| Maximum Recovered Inside Diameter (In.) | 0.5 |
| Maximum Recovered Inside Diameter (mm) | 12.7 |
Panduit Panduit HST1.5-9-XY | Heat Shrink | UPC - 07498310738 Data Sheets
| Catalog Cut Sheets | Catalog Cut Sheet - HST0.4-3-Q2Y Product Page | Download and View |
| Specification Sheets | Thick Wall Polyolefin Heat Shrink Tubing: HSSP02-WW-ENG | Download and View |
| Part Drawings | Part Drawing - PDF - GB0239KM_03A | Download and View |
Panduit Panduit HST1.5-9-XY | Heat Shrink | UPC - 07498310738 Environmental Information
| Panduit's RoHS Statement | Download and View |
