Panduit HSTT12-C | Dry-Shrink HSTT12-C Heat Shrink
Regular price
$1.46
Unit price
Description
Description
Panduit HSTT12-C | Dry-Shrink HSTT12-C Heat Shrink
Thin wall heat shrink, .12" (3.2mm) diameter, black cross-linked polyolefin, 100 ft. (30.5m) per reel.
Panduit HSTT12-C - TUBING - 1/8" PO HEAT SHRINK 2:1
Specifications
Specifications
Panduit - HSTT12-C - Product Categories
- Wire Routing, Management & Protection
- Heat Shrink Tubing
Panduit - HSTT12-C - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | HSTT12-C |
| Item Description | Dry-Shrink HSTT12-C Heat Shrink |
| Product Type | Heat Shrink |
| Adhesive Lined | No |
| Color | Black |
| Material | Flame retardant polyolefin cross-linked except clear |
| Maximum Operating Temperature (°C) | 135 |
| Maximum Operating Temperature (°F) | 275 |
| Minimum Operating Temperature (°C) | -55 |
| Minimum Operating Temperature (°F) | -67 |
| Nominal Diameter (In.) | 0.125 |
| Nominal Diameter (mm) | 3.2 |
| Nominal Recovered Wall Thickness (In.) | 0.02 |
| Nominal Recovered Wall Thickness (mm) | 0.5 |
| Sub Brand | Dry-Shrink |
| Overall Length (In.) | 1200 |
| Overall Length (ft.) | 100 |
| Overall Length (m) | 30.5 |
| Overall Length (mm) | 30480 |
| Standards Met | UL Recognized, CSA Approved, MIL SPEC |
| Shrink Ratio | 2:1 |
| Shrink Temperature (°C) | 90 |
| Shrink Temperature (°F) | 194 |
| Maximum Recovered Inside Diameter (In.) | 0.062 |
| Maximum Recovered Inside Diameter (mm) | 1.6 |
| Minimum Expanded Inside Diameter (In.) | 0.125 |
| Minimum Expanded Inside Diameter (mm) | 3.2 |
| Application | For Dry Locations |
| Part Features | 2:1 shrink ratio for dry applications. Provides excellent abrasion protection and color coding. Flexible |
Panduit - HSTT12-C - Package Information
| UPC | 07498374701 |
|---|---|
| Standard Package Quantity | 1 |
| Standard Package Volume (cf) | 0.0630 |
| Standard Ctn. Quantity | 10 |
| Standard Ctn. Volume (cf) | 0.6302 |
Panduit - HSTT12-C - Videos
| Video 1 | Click to View |
|---|
