Panduit HSTT12-YK1 | Dry-Shrink™ Thin Wall Heat Shrink Tubing
Description
Description
Panduit Dry-Shrink Heat Shrink Tubing, Type HSTT, 600 VAC, 1/8 in Inner Dia Expanded, 0.062 in Inner Dia Recovered, Thin Wall, 0.02 in Wall Thickness Recovered, 2:1 Shrink, 6 in Length, -67 to 275 deg F, 194 deg F Shrink, Polyolefin, Assorted
Reduce bulk with our dry-shrink tubing, provides quick and easy protection for wires, connectors, and terminals in dry indoor environments, offering insulation and abrasion resistance.
Thin wall heat shrink in 6" pieces, multi-color, single diameter, .12" (3.2mm) diameter, cross-linked polyolefin.
Panduit - HSTT12-YK1 - Features
- These small cables minimize waste, optimize cable management, speed deployment, improve flexibility and manageability
- Typically used for connectivity between the switch in horizontal cabling
- Installs into QuickNet MPO patch panels on one end and switch ports on the other end
- New cable management transition allows multiple harnesses to attach to each other or be secured to a rack or cabinet with Tak-Ty hook and loop cable ties
- Applications: For Dry Locations
- Without adhesive liner
Specifications
Specifications
Panduit - HSTT12-YK1 - Specifications
| Heat Shrink | Yes Is Shrink Tubing |
|---|---|
| Mil Spec | No |
| Material/Type | Po-Polyolefin |
| Military Color Code | Black |
| Sleeving | Yes |
| Spiral Wrap | No |
| Zipper | No |
| UNSPSC Code | 39121723 |
| Product Type | Heat Shrink Tubing |
| Adhesive Lined | No |
| Color | Various |
| Material | Cross-Linked Polyolefin |
| Maximum Operating Temperature (°C) | 135 |
| Maximum Operating Temperature (°F) | 275 |
| Minimum Operating Temperature (°C) | -55 |
| Minimum Operating Temperature (°F) | -67 |
| Nominal Diameter (In.) | 0.125 |
| Nominal Diameter (mm) | 3.2 |
| Nominal Recovered Wall Thickness (In.) | 0.02 |
| Nominal Recovered Wall Thickness (mm) | 0.5 |
| Sub Brand | Dry-Shrink™ |
| Overall Length (In.) | 6 |
| Overall Length (ft.) | 0.5 |
| Overall Length (m) | 0.15 |
| Overall Length (mm) | 152.4 |
| Resistance Properties | Flame-Retardant |
| Standards Met | UL Recognized, CSA Approved, MIL SPEC |
| Shrink Ratio | 2:1 |
| Shrink Temperature (°C) | 90 |
| UPC | 07498390762 |
Panduit - HSTT12-YK1 - Package Information
| UPC | 07498390762 |
|---|---|
| Standard Packaging Quantity | 1 |
| Standard Packaging Volume (cf) | 0.0175 |
| Standard Ctn. Quantity | 10 |
| Standard Ctn. Volume (cf) | 0.1750 |
