Brand: Panduit
|
SKU:
10045121-EA
Panduit HSTT400-48-2C | Dry-Shrink HSTT400-48-2C Heat Shrink
Regular price
$127.15
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit HSTT400-48-2C | Dry-Shrink HSTT400-48-2C Heat Shrink
Regular price
$127.15
Unit price
Description
Description
Panduit HSTT400-48-2C | Dry-Shrink HSTT400-48-2C Heat Shrink
Thin wall heat shrink, 4" (101.6mm) diameter, clear cross-linked polyolefin, 2 pc. package quantity.
Panduit HSTT400-48-2C - HEAT SHRINK - HEAT SHRINK THIN, 4"DIA, CLEAR
Specifications
Specifications
Panduit - HSTT400-48-2C - Product Categories
- Wire Routing, Management & Protection
- Heat Shrink Tubing
Panduit - HSTT400-48-2C - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | HSTT400-48-2C |
| Item Description | Dry-Shrink HSTT400-48-2C Heat Shrink |
| Product Type | Heat Shrink |
| Adhesive Lined | No |
| Color | Clear |
| Material | Polyolefin cross-linked |
| Maximum Operating Temperature (°C) | 135 |
| Maximum Operating Temperature (°F) | 275 |
| Minimum Operating Temperature (°C) | -55 |
| Minimum Operating Temperature (°F) | -67 |
| Nominal Diameter (In.) | 4 |
| Nominal Diameter (mm) | 101.6 |
| Nominal Recovered Wall Thickness (In.) | 0.055 |
| Nominal Recovered Wall Thickness (mm) | 1.4 |
| Sub Brand | Dry-Shrink |
| Overall Length (In.) | 48 |
| Overall Length (ft.) | 4 |
| Overall Length (m) | 1.2 |
| Overall Length (mm) | 1219 |
| Standards Met | UL Recognized, CSA Approved, MIL SPEC |
| Shrink Ratio | 2:1 |
| Shrink Temperature (°C) | 90 |
| Shrink Temperature (°F) | 194 |
| Maximum Recovered Inside Diameter (In.) | 2 |
| Maximum Recovered Inside Diameter (mm) | 50.8 |
| Minimum Expanded Inside Diameter (In.) | 4 |
| Minimum Expanded Inside Diameter (mm) | 101.6 |
| Application | For Dry Locations |
Panduit - HSTT400-48-2C - Package Information
| UPC | 07498390670 |
|---|---|
| Standard Package Quantity | 2 |
| Standard Package Volume (cf) | 0.3893 |
| Standard Ctn. Quantity | 0 |
| Standard Ctn. Volume (cf) | 0.0000 |
Panduit - HSTT400-48-2C - Videos
| Video 1 | Click to View |
|---|
