Brand: Panduit
|
SKU:
277418
Panduit HSTT50-T | Dry-Shrink Hstt50-T Heat Shrink
Regular price
$253.03
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit HSTT50-T | Dry-Shrink Hstt50-T Heat Shrink
Regular price
$253.03
Unit price
Description
Description
Panduit HSTT50-T | Dry-Shrink Hstt50-T Heat Shrink
Thin wall heat shrink, .50" (12.7mm) diameter, black cross-linked polyolefin, 200 ft. (61.0m) per reel.
Panduit - HSTT50-T - Features
- Panduit Dry-Shrink Heat Shrink Tubing, Type HSTT Standard, 600 VAC, 1/2 in Inner Dia Expanded, 1/4 in Inner Dia Recovered, Thin Wall, 0.025 in Wall Thickness Recovered, 2:1 Shrink, 200 ft Reel Length, -67 to 275 deg F, 194 deg F Shrink, Cross-Linked Polyolefin, Black
- Without adhesive liner
Specifications
Specifications
Panduit - HSTT50-T - Product Categories
- Wire Routing, Management & Protection
- Heat Shrink Tubing
Panduit - HSTT50-T - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | HSTT50-T |
| Item Description | Dry-Shrink Hstt50-T Heat Shrink |
| Product Type | Heat Shrink |
| Adhesive Lined | No |
| Color | Black |
| Material | Flame retardant polyolefin cross-linked except clear |
| Maximum Operating Temperature (°C) | 135 |
| Maximum Operating Temperature (°F) | 275 |
| Minimum Operating Temperature (°C) | -55 |
| Minimum Operating Temperature (°F) | -67 |
| Nominal Diameter (In.) | 0.5 |
| Nominal Diameter (mm) | 12.7 |
| Nominal Recovered Wall Thickness (In.) | 0.025 |
| Nominal Recovered Wall Thickness (mm) | 0.6 |
| Sub Brand | Dry-Shrink |
| Overall Length (In.) | 2400 |
| Overall Length (ft.) | 200 |
| Overall Length (m) | 61 |
| Overall Length (mm) | 60960 |
| Standards Met | UL Recognized, CSA Approved, MIL SPEC |
| Shrink Ratio | 2:1 |
| Shrink Temperature (°C) | 90 |
| Shrink Temperature (°F) | 194 |
| Maximum Recovered Inside Diameter (In.) | 0.25 |
| Maximum Recovered Inside Diameter (mm) | 6.4 |
| Minimum Expanded Inside Diameter (In.) | 0.5 |
| Minimum Expanded Inside Diameter (mm) | 12.7 |
| Application | For Dry Locations |
| Part Features | 2:1 shrink ratio for dry applications. Provides excellent abrasion protection and color coding. Flexible |
| MPN: | HSTT50-T |
| Color: | Black |
| Inner Diameter Expanded: | 1/2 in |
| Inner Diameter Recovered: | 1/4 in |
| Length: | 200 ft Reel |
| Material: | Cross-Linked Polyolefin |
| Series: | HSTT |
| Shrink Ratio: | 0.08 |
| Shrink Temperature: | 194 deg F |
| Temperature Rating: | -67 to 275 deg F |
| Type: | Type HSTT Standard |
| Voltage Rating: | 600 VAC |
| Wall Thickness Recovered: | 0.025 in |
| Wall Type: | Thin |
Panduit - HSTT50-T - Package Information
| UPC | 07498391389 |
|---|---|
| Standard Package Quantity | 1 |
| Standard Package Volume (cf) | 0.3838 |
| Standard Ctn. Quantity | 2 |
| Standard Ctn. Volume (cf) | 0.7677 |
