Brand: Panduit
|
SKU:
HSTT75-48-5C
Panduit HSTT75-48-5C | Thin wall heat shrink, .75"; (19.0mm) diameter, clear cross-linked polyolefin, 5 pc. package quantity.
Regular price
$8.90
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit HSTT75-48-5C | Thin wall heat shrink, .75"; (19.0mm) d...
Regular price
$8.90
Unit price
Description
Description
Panduit HSTT75-48-5C | Dry-Shrink HSTT75-48-5C Heat Shrink
Thin wall heat shrink, .75" (19.0mm) diameter, clear cross-linked polyolefin, 5 pc. package quantity.
Specifications
Specifications
Panduit - HSTT75-48-5C - Product Categories
- Wire Routing, Management & Protection
- Heat Shrink Tubing
Panduit - HSTT75-48-5C - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | HSTT75-48-5C |
| Item Description | Dry-Shrink HSTT75-48-5C Heat Shrink |
| Product Type | Heat Shrink |
| Adhesive Lined | No |
| Color | Clear |
| Material | Polyolefin cross-linked |
| Maximum Operating Temperature (°C) | 135 |
| Maximum Operating Temperature (°F) | 275 |
| Minimum Operating Temperature (°C) | -55 |
| Minimum Operating Temperature (°F) | -67 |
| Nominal Diameter (In.) | 0.75 |
| Nominal Diameter (mm) | 19.1 |
| Nominal Recovered Wall Thickness (In.) | 0.03 |
| Nominal Recovered Wall Thickness (mm) | 0.8 |
| Sub Brand | Dry-Shrink |
| Overall Length (In.) | 48 |
| Overall Length (ft.) | 4 |
| Overall Length (m) | 1.2 |
| Overall Length (mm) | 1219 |
| Standards Met | UL Recognized, CSA Approved, MIL SPEC |
| Shrink Ratio | 2:1 |
| Shrink Temperature (°C) | 90 |
| Shrink Temperature (°F) | 194 |
| Maximum Recovered Inside Diameter (In.) | 0.375 |
| Maximum Recovered Inside Diameter (mm) | 9.5 |
| Minimum Expanded Inside Diameter (In.) | 0.75 |
| Minimum Expanded Inside Diameter (mm) | 19.1 |
| Application | For Dry Locations |
Panduit - HSTT75-48-5C - Package Information
| UPC | 07498390665 |
|---|---|
| Standard Pkg. Qty. | 5 |
| Standard Package Volume (cf) | 0.1737 |
| Standard Ctn. Qty. | 0 |
| Standard Ctn. Volume (cf) | 0.0000 |
Panduit - HSTT75-48-5C - Videos
| Video 1 | Click to View |
|---|
