Brand: Panduit
|
SKU:
10045205
Panduit HSTTPN100-CC | Heat Shrink | UPC - 07498381349
Regular price
$537.84
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit HSTTPN100-CC | Heat Shrink | UPC - 07498381349
Regular price
$537.84
Unit price
Description
Description
Panduit Dry-Shrink Heat Shrink Tubing, Type HSTTPN Standard, 600 VAC, 0.9 in Inner Dia Expanded, 1/2 in Inner Dia Recovered, Thin Wall, 0.03 in Wall Thickness Recovered, 2:1 Shrink, 100 ft Reel Length, -4 to 221 deg F, 212 deg F Shrink, PVC, Clear
Features + Benefits
- Low shrink temperature store below 90 deg F to speed installation
- Crystal clear material ensures easy to read labels and splice inspections
- Shrink ratio of 2:1 insulates a wide range of diameters and irregular shapes
- Highly flame-retardant product manufactured from a material that is rated UL 224 VW-1
Panduit Panduit HSTTPN100-CC | Heat Shrink | UPC - 07498381349 Key Specs
| Product Type | Heat Shrink |
| Color | Clear |
| Material | PVC |
| Nominal Diameter (In.) | 1 |
| Nominal Diameter (mm) | 25.4 |
| Nominal Recovered Wall Thickness (In.) | 0.03 |
| Nominal Recovered Wall Thickness (mm) | 0.8 |
| Sub Brand | Dry-Shrink |
| Overall Length (In.) | 1200 |
| Overall Length (ft.) | 100 |
| Overall Length (m) | 30.5 |
| Overall Length (mm) | 30480 |
| Shrink Ratio | 2:1 |
| Minimum Expanded Inside Diameter (In.) | 0.9 |
| Minimum Expanded Inside Diameter (mm) | 22.9 |
| Application | For Dry Locations |
Panduit Panduit HSTTPN100-CC | Heat Shrink | UPC - 07498381349 Data Sheets
| Catalog Cut Sheets | Catalog Cut Sheet - HSTTPN50-438-L Product Page | Download and View |
| Part Drawings | Part Drawing - PDF - HSTTPN PVC Heat Shrink | Download and View |
| MSDS | MSDS- Heat Shrinkable Tubing | Download and View |
Panduit Panduit HSTTPN100-CC | Heat Shrink | UPC - 07498381349 Environmental Information
| Panduit's RoHS Statement | Download and View |
