Panduit HTCT2-2-1 | Structured Ground Compression Connectors - Taps
Description
Description
Provide a secure and reliable electrical ground connection with our copper compression tap. It's ideal for connecting grounding conductors to metal conduits or enclosures.
Copper Compression HTAP with code #2 - #6 AWG STR/SOL Run and Tap 1, code #8 - #14 AWG Tap 2 and Tap 3 or flex #2 - #8 AWG Run and Tap 1 and flex #8 - #14 AWG Tap 2 and Tap 3.
Panduit StructuredGround Compression H-Tap Connector, Series: HTCT, H Shape, 3 Total Taps, 6 to 2 AWG Stranded/Solid Code, 8 to 2 AWG Flexible Main/Run, 6 to 2 AWG Solid/Stranded Code, 8 to 2 AWG Flexible Tap, 600 VAC, Code/Flex Conductor, Specifications: 2 to 6 A, 13/16 in L Wire Strip, Copper, Tin Plated, 0.76 in L x 0.61 in W x 1.55 in H Dimensions
Panduit - HTCT2-2-1 - Features
- Used to tap into continuous conductors as a splice or pigtailing
- Each HTAP terminates a wide range of conductor sizes and combinations of code and flex conductors class G, H, I and diesel locomotive to suit a variety of applications
- Slotted design allows quick and easy assembly of conductor to HTAP using three Panduit 94V-0 cable ties included
- Tap grooves are separated from one another allowing them to function independently so HTAP can be used with a single or multiple taps providing maximum design and installation flexibility
- Color coded and marked with Panduit die index numbers for proper crimp die selection
Specifications
Specifications
Panduit - HTCT2-2-1 - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | HTCT2-2-1 |
| Component | Compression Taps |
| Connection Type | Compression |
| Material Rating | Copper |
| UNSPSC Code | 39121400 |
| Sub Brand | StructuredGround |
| Surface Treatment | Tinned |
| Overall Length (In.) | 0.76 |
| Overall Length (mm) | 19.3 |
| Overall Width (In.) | 0.61 |
| Overall Width (mm) | 15.5 |
| Overall Height (In.) | 1.55 |
| Overall Height (mm) | 39.4 |
| Maximum Tap 1 Size (AWG) | 2 |
| Minimum Tap 1 Size (AWG) | 8 |
| Maximum Tap 2 Size (AWG) | 8 |
| Minimum Tap 2 Size (AWG) | 14 |
| Maximum Tap 3 Size (AWG) | 8 |
| Minimum Tap 3 Size (AWG) | 14 |
| Wire Strip Length (In.) | 13/16 |
| Wire Strip Length (mm) | 21 |
| Panduit Die Index Number | PH2 |
| Color Code | Brown |
| Standards Met | cULus listed and CSA certified |
| Application | Telecom/Data Center |
| Product Type | Compression Tap |
| UPC | 07498344075 |
Panduit - HTCT2-2-1 - Videos
| Panduit HTCT2-2-1 Video 1 | Click to View |
|---|
