Panduit HTCT6X-6X-1 | Structured Ground Compression Tap
Description
Description
Provide a secure and reliable electrical ground connection with our copper compression tap. It's ideal for connecting grounding conductors to metal conduits or enclosures.
Copper Compression HTAP with code #6 - #14 AWG Run, code #6 - #14 AWG Tap 1 or flex #6 - #14 AWG Run and flex #6 - #14 AWG Tap1.
Panduit StructuredGround Compression H-Tap Connector, Series: HTCT, H Shape, 1 Total Taps, 14 to 6 AWG Main/Run, 14 to 6 AWG Tap, 600 VAC, Code/Flex Conductor, Specifications: 11/16 in L Wire Strip, Orange Color, Copper, Tin Plated, 0.6 in L x 0.4 in W x 1 in H Dimensions
Panduit - HTCT6X-6X-1 - Features
- Used to tap into continuous conductors as a splice or pigtailing
- Each HTAP terminates a wide range of conductor sizes and combinations of code and flex conductors class G, H, I and diesel locomotive to suit a variety of applications
- Slotted design allows quick and easy assembly of conductor to HTAP using three Panduit 94V-0 cable ties included
- Tap grooves are separated from one another allowing them to function independently so HTAP can be used with a single or multiple taps providing maximum design and installation flexibility
- Color coded and marked with Panduit die index numbers for proper crimp die selection
Specifications
Specifications
Panduit - HTCT6X-6X-1 - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | HTCT6X-6X-1 |
| Component | Compression Taps |
| Connection Type | Compression |
| Material Rating | Copper |
| UNSPSC Code | 39121400 |
| Sub Brand | StructuredGround |
| Material | Copper |
| Surface Treatment | Tinned |
| Overall Length (In.) | 0.6 |
| Overall Length (mm) | 15.2 |
| Overall Width (In.) | 0.4 |
| Overall Width (mm) | 10.2 |
| Overall Height (In.) | 1 |
| Overall Height (mm) | 25.4 |
| Maximum Tap 1 Size (AWG) | 6 |
| Minimum Tap 1 Size (AWG) | 14 |
| Maximum Tap 2 Size (AWG) | 6 |
| Wire Strip Length (In.) | 11/16 |
| Wire Strip Length (mm) | 18 |
| Panduit Die Index Number | PH6 |
| Color Code | Orange |
| Standards Met | cULus listed, CSA certified |
| Application | Telecom/Data Center |
| Product Type | Compression Tap |
| Part Features | Slotted design allows quick and easy assembly of conductor to HTAP using three Panduit 94V-0 cable ties included |
| UPC | 07498332271 |
Panduit - HTCT6X-6X-1 - Environmental Information
| RoHS Status | ROHS3 Compliant |
|---|---|
| Moisture Sensitivity Level (MSL) | Not Applicable |
| ECCN | EAR99 |
| HTSUS | 7419.99.5050 |
Panduit - HTCT6X-6X-1 - Videos
| Panduit HTCT6X-6X-1 Video 1 | Click to View |
|---|
