Panduit IFRH5C04BL-UG | Copper Cable/Industrial | UPC - 61305634699

The Cat 5e UTP copper cable is constructed of 24 AWG copper conductors with HDPE insulation. The copper conductors are twisted in pairs and wrapped with a foam polypropylene tape to form a core. All four pairs are covered with an industrially rated black PVC jacket which is oil and sunlight resistant and flame retardant. This cable is rated for panel or on-machine applications where space is shared with 600 V high voltage cables. The cable is supplied 305 meters (1,000 feet) to a reel and black.

---

Panduit IFRH5C04BL-UG | Copper Cable/Industrial | UPC - 61305634699 Key Specs

Environment	Outdoor
Performance Level	Category 5e
Cable Construction	F/UTP
Flammability Rating	Outdoor
EuroClass Rating	Fca
Resistance Properties	UV Resistant
Jacket Material	High Density Polyethylene
Nominal Cable Outside Diameter (In.)	0.25
Nominal Cable Outside Diameter (mm)	6.6
Maximum Operating Temperature (°C)	75
Maximum Operating Temperature (°F)	167
Minimum Operating Temperature (°C)	-40
Minimum Operating Temperature (°F)	-40
Maximum Installation Temperature (°C)	75
Maximum Installation Temperature (°F)	167
Minimum Installation Temperature (°C)	-20
Minimum Installation Temperature (°F)	-4
Sub Brand	IndustrialNet
Maximum Installation Tension (lb)	25
