Panduit IFRH6C04BL-UG | Copper Cable/Industrial | UPC - 61305602249

This Cat 6 F/UTP copper cable is constructed of 23 AWG solid copper conductors with HDPE insulation. The copper conductors are twisted in pairs and wrapped with a foam polypropylene tape to form a core. All four pairs are covered with an industrially rated black PVC jacket which is oil and sunlight resistant and flame retardant. The cable is supplied 305 meters (1,000 feet) to a reel and black.

---

Panduit Panduit IFRH6C04BL-UG | Copper Cable/Industrial | UPC - 61305602249 Key Specs

Environment	Outdoor
Performance Level	Category 6
Cable Construction	F/UTP
Flammability Rating	Outdoor
Resistance Properties	UV Resistant
Jacket Material	High Density Polyethylene
Nominal Cable Outside Diameter (In.)	0.34
Nominal Cable Outside Diameter (mm)	8.7
Maximum Operating Temperature (°C)	75
Maximum Operating Temperature (°F)	167
Minimum Operating Temperature (°C)	-40
Minimum Operating Temperature (°F)	-40
Maximum Installation Temperature (°C)	75
Maximum Installation Temperature (°F)	167
Minimum Installation Temperature (°C)	-20
Minimum Installation Temperature (°F)	-4
Sub Brand	IndustrialNet
Maximum Installation Tension (lb)	25
Maximum Installation Tension (N)	110
