Brand: Panduit | SKU: 330241

Panduit J318-412-T | Pan-Term J318-412-T Wire Joint

Name: Panduit J318-412-T | Pan-Term J318-412-T Wire Joint
Brand: Anixter
SKU: 330241
Price: 70.49 USD
Availability: InStock

$70.49

Shipping calculated at checkout.

Description

Panduit J318-412-T Non-Insulated Insulated Wire Joint

Panduit J Series - Cable wire joint - metallic - J318-412-T.

Brand Name	Panduit
Manufacturer Part Number	J318-412-T
Item Description	Pan-Term J318-412-T Wire Joint
Product Type	Wire Joint
Base Material	Steel
Wire Strip Length (In.)	0.5
Color Code	Metallic
Finish/Coating	Tin-Plated
Insulation Material	Non-Insulated
Maximum Copper Conductor Size (AWG SOL)	#10
Maximum Copper Conductor Size (AWG STR)	#10
Minimum Copper Conductor Size (AWG SOL)	#18
Minimum Copper Conductor Size (AWG STR)	#18
Maximum Operating Temperature (°C)	150
Maximum Operating Temperature (°F)	302
Maximum Voltage (V)	2
Overall Length (In.)	0.37
Overall Length (mm)	9.4
Inside Diameter (In.)	0.21
Inside Diameter (mm)	5.33
Standards Met	UL486C, CSA C22.2 No 65
Wire Strip Length (mm)	12.7
Packaging Type	Bottle
For Use With	CT-100, CT-200
Sub Brand	Pan-Term
Copper Conductor Size (AWG)	#18 - #10
Maximum Metric Conductor Size (mm²)	6
Minimum Metric Conductor Size (mm²)	1
