Panduit LAA1/0-38-L | Pan-Lug Aluminum Compression Lugs
Regular price
$11.62
Unit price
Brand: Panduit
|
SKU:
PAN-LAA1/0-38-L
Regular price
$11.62
Unit price
Description
Description
Panduit LAA1/0-38-L | Pan-Lug Aluminum Compression Lugs
The LAA1/0-38-L Aluminum Compression Connector Lug, one hole, is manufactured from high conductivity thick wall aluminum with an enclosed barrel for harsh environments. The color-coded barrels are marked with Panduit and specified competitor die index numbers for proper crimp die selection. Factory pre-filled with joint compound and tin-plated to inhibit corrosion. cULus listed up to 35kV and temperature rated to 90°C.
Specifications
Specifications
Panduit - LAA1/0-38-L - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | LAA1/0-38-L |
| Item Description | Pan-Lug Aluminum Compression Lugs |
| Product Type | Compression Lug |
| Lug Type | 1 Stud Hole Aluminum Lug |
| Base Material | Aluminum |
| Aluminum Conductor Size (AWG) | 1/0 |
| Copper Code Conductor Size (AWG) | 1/0 |
| Sub Brand | Pan-Lug |
| Stud Hole Size (In.) | 0.41 |
| Stud Hole Size (mm) | 10.41 |
| Barrel Type | Standard |
| Barrel Length (In.) | 1.25 |
| Barrel Length (mm) | 31.75 |
| Tongue Type | Standard |
| Tongue Width (In.) | 0.88 |
| Tongue Width (mm) | 22.35 |
| Tongue Angle | Straight |
| Tongue Thickness (In.) | 0.25 |
| Tongue Thickness (mm) | 6.35 |
| Overall Length (In.) | 3.22 |
| Overall Length (mm) | 81.78 |
| Finish/Coating | Tin-Plated |
| Standards Met | UL listed and CSA certified |
| UL Temperature Rating (°C) | 90 |
| Maximum Voltage (kV) | 35 |
| Color Code | Tan |
| Panduit Die Index Number | P50 |
| Burndy Die Index Number | 296 |
| T & B Die Index Number | 50 |
| Wire Strip Length (In.) | 42614 |
| Includes | Connector barrel pre-filled with oxide inhibiting joint compound |
