Panduit LAA2-38-70 | Pan-Lug LAA2-38-70 Aluminum Compression Lugs
The LAA2-38-70 Aluminum Compression Connector Lug, one hole, is manufactured from high conductivity thick wall aluminum with an enclosed barrel for harsh environments. The color-coded barrels are marked with Panduit and specified competitor die index numbers for proper crimp die selection. Factory pre-filled with joint compound and tin-plated to inhibit corrosion. cULus listed up to 35kV and temperature rated to 90°C.
Specifications
Specifications
Panduit - LAA2-38-70 - Product Categories
- Wire Termination
- Mechanical & Compression Lugs & Splices
Panduit - LAA2-38-70 - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | LAA2-38-70 |
| Item Description | Pan-Lug LAA2-38-70 Aluminum Compression Lugs |
| Product Type | Compression Lug |
| Lug Type | 1 Stud Hole Aluminum Lug |
| Base Material | Aluminum |
| Aluminum Conductor Size (AWG) | 2 |
| Copper Code Conductor Size (AWG) | 2 |
| Sub Brand | Pan-Lug |
| Stud Hole Size (In.) | 0.41 |
| Stud Hole Size (mm) | 10.41 |
| Barrel Type | Standard |
| Barrel Length (In.) | 1 |
| Barrel Length (mm) | 25.4 |
| Tongue Type | Standard |
| Tongue Width (In.) | 0.79 |
| Tongue Width (mm) | 20.06 |
| Tongue Angle | Straight |
| Tongue Thickness (In.) | 0.17 |
| Tongue Thickness (mm) | 4.31 |
| Overall Length (In.) | 2.63 |
| Overall Length (mm) | 66.8 |
| Finish/Coating | Tin-Plated |
| Standards Met | UL listed and CSA certified |
| UL Temperature Rating (°C) | 90 |
| Maximum Voltage (kV) | 35 |
| Color Code | Pink |
| Panduit Die Index Number | P42 |
| Burndy Die Index Number | 348 |
| T & B Die Index Number | 42 |
| Wire Strip Length (In.) | 1 |
| Includes | Connector barrel pre-filled with oxide inhibiting joint compound |
Brand Name - LAA2-38-70 - Package Information
| UPC | 61305685780 |
|---|---|
| Standard Package Quantity | 70 |
| Standard Package Volume (cf) | 0.0191 |
| Standard Ctn. Quantity | 280 |
| Standard Ctn. Volume (cf) | 0.0763 |
