Brand: Panduit
|
SKU:
PAN-LCAF2/0-38H
Panduit LCAF2/0-38H-X | Tin-Plated Copper Compression Connectors - Lugs | UPC - 07498387269
Regular price
$11.43
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit LCAF2/0-38H-X | Tin-Plated Copper Compression Connectors - ...
Regular price
$11.43
Unit price
Brand: Panduit
|
SKU:
PAN-LCAF2/0-38H
Regular price
$11.43
Unit price
Shipping calculated at checkout.
Description
Description
Panduit Pan-Lug Lug Compression Connector, 1-Hole, Series: LCAF, 2/0 AWG Conductor, Die Code: P50, 35 kV, 3/8 in Stud, 45 deg Tongue, 0.96 in W x 0.13 in THK Tongue, 1.98 in Overall Length, Standard Barrel, 1.35 in L Barrel, 90 deg C, 1-7/16 in Mounting Hole, Tin Plated Copper, Orange
Features + Benefits
- Color coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection
- Inspection window to visually assure full conductor insertion
- Tin plated to inhibit corrosion
Panduit LCAF2/0-38H-X | Tin-Plated Copper Compression Connectors - Lugs | UPC - 07498387269 Key Specs
| Product Type | Tin-Plated Copper Compression Connectors - Lugs |
| Stud Hole Size (In.) | 3/8 |
| Stud Hole Size (mm) | 9.5 |
| Tongue Type | Standard Tongue Width |
| Tongue Angle | 45° |
| Tongue Thickness (In.) | 0.13 |
| Tongue Thickness (mm) | 3.3 |
| Tongue Width (In.) | 0.96 |
| Tongue Width (mm) | 24.4 |
| Overall Length (In.) | 2.14 |
| Overall Length (mm) | 54.4 |
| Barrel Type | Standard Barrel Length with Inspection Window |
| Barrel Length (In.) | 1.35 |
| Barrel Length (mm) | 34.3 |
| Sub Brand | Pan-Lug |
| Wire Strip Length (In.) | 14375.00 |
| Wire Strip Length (mm) | 36.5 |
| Part Features | Tin plated to inhibit corrosion,color coded barrel,inspection window, NEBS level 3. |
Panduit LCAF2/0-38H-X | Tin-Plated Copper Compression Connectors - Lugs | UPC - 07498387269 Data Sheets
| Catalog Cut Sheets | Catalog Cut Sheet - LCAF8-10H-L Product Page | Download and View |
| Part Drawings | Part Drawing - PDF - LCAF2_038H-X | Download and View |
| Selection Guides | Power Connector Tool and Die Selection Guides | Download and View |
Panduit LCAF2/0-38H-X | Tin-Plated Copper Compression Connectors - Lugs | UPC - 07498387269 Environmental Information
| Panduit's RoHS Statement | Download and View |
