Panduit LCAF3/0-38F-X | Pan-Lug™ Copper 1 Hole Straight Tongue Comp...
Description
Description
Panduit Pan-Lug Compression Lug, 1-Hole, Series: LCAF, Copper Conductor, 3/0 AWG Class K, M and DLO Conductor, Die Code: P54, 35 kV, 3/8 in Stud, 90 deg Long Tongue, 0.86 in L x 1.06 in W x 0.14 in THK Tongue, 1.89 in Overall Length, Flared/Standard With Inspection Window Barrel, 0.57 in ID x 0.81 in OD x 1.35 in L Barrel, 1-7/16 in L Wire Strip, 90 deg C, 1-7/16 in Mounting Hole, Tin Plated Copper, Purple
Reliable, one-hole solution for connecting large wires in electrical applications, with our copper 1-hole straight tongue compression lug.
One-hole, flared barrel, 3/0 AWG wire, 3/8 stud hole, 90 angle tongue.
Panduit - LCAF3/0-38F-X - Features
- These small cables minimize waste, optimize cable management, speed deployment, improve flexibility and manageability
- Typically used for connectivity between the switch in horizontal cabling
- Installs into QuickNet MPO patch panels on one end and switch ports on the other end
- New cable management transition allows multiple harnesses to attach to each other or be secured to a rack or cabinet with Tak-Ty hook and loop cable ties
- Color-coded bands for proper die selection and crimp placement
- Can be used with flex conductor class K, M and diesel locomotive
- Flared entry prevents bent back strands when inserting fine strand conductor into barrel
- Inspection window to assure complete conductor insertion
- Tin-plated to inhibit corrosion
Specifications
Specifications
Panduit - LCAF3/0-38F-X - Specifications
| Barrel | Standard |
|---|---|
| Bolt Hole | 3/8 Inch |
| Gauge | 3/0 Awg |
| Holes | 1 Hole |
| Inspection Hole | Yes |
| Lug Material | Copper |
| Type | Standard Compression |
| UNSPSC Code | 39121400 |
| Product Type | Compression Lug |
| Base Material | Copper |
| Number of Stud Holes | 1 |
| Barrel Type | Standard |
| Barrel Entry | Flared |
| Tongue Type | Standard |
| Tongue Angle | 90° |
| Inspection Window | Yes |
| Finish/Coating | Tin-Plated |
| Stud Hole Size (In.) | 3/8 |
| Stud Hole Size (mm) | 9.5 |
| Class K Copper Flex Conductor Size (AWG) | 3/0 |
| Class M Copper Flex Conductor Size (AWG) | 3/0 |
| DLO Copper Flex Conductor Size (AWG) | 3/0 |
| Barrel Length (In.) | 1.35 |
| Barrel Length (mm) | 34.3 |
| Tongue Width (In.) | 1.06 |
| Tongue Width (mm) | 26.9 |
| Tongue Thickness (In.) | 0.14 |
| Tongue Thickness (mm) | 3.6 |
| Overall Length (In.) | 1.89 |
| UPC | 07498387714 |
Panduit - LCAF3/0-38F-X - Package Information
| UPC | 07498387714 |
|---|---|
| Standard Packaging Quantity | 10 |
| Standard Packaging Volume (cf) | 0.0370 |
| Standard Ctn. Quantity | 0 |
| Standard Ctn. Volume (cf) | 0.0000 |
