Panduit LCAX350-38H-6 | Pan-Lug Copper Compression Connectors - Lugs
Regular price
$26.36
Unit price
Brand: Panduit
|
SKU:
670885
Regular price
$26.36
Unit price
Description
Description
Panduit LCAX350-38H-6 | Pan-Lug Copper Compression Connectors - Lugs
Connect large wires securely with our copper 1-hole tongue compression lug, its 45° angle offers increased flexibility and reliability in electrical applications.
Panduit Pan-Lug Lug Compression Connector, 1-Hole, Series: LCAX, Flexible Conductor, 350 kcmil, 373.7 kcmil Conductor, Die Code: P76, 35 kV, 3/8 in Stud, 45 deg Tongue, 1.54 in W x 0.22 in THK Tongue, 1.62 in Overall Length, Standard Barrel, 1.29 in L Barrel, 90 deg C, 1-3/8 in Mounting Hole, Tin Plated Copper, Blue
Panduit - LCAX350-38H-6 - Features
- Generously beveled wire entry prevents bent back strands when inserting conductor into barrel
- Color coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection
- Inspection window to visually assure full conductor insertion
- Tin plated to inhibit corrosion
Specifications
Specifications
Panduit - LCAX350-38H-6 - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | LCAX350-38H-6 |
| Product Type | Compression Lug |
| Base Material | Copper |
| Number of Stud Holes | 1 |
| Barrel Type | Standard |
| Barrel Entry | Beveled |
| Tongue Type | Standard |
| Tongue Angle | 45° |
| Inspection Window | Yes |
| Finish/Coating | Tin-Plated |
| Stud Hole Size (In.) | 3/8 |
| Stud Hole Size (mm) | 9.5 |
| Stud Hole Spacing (mm) | 0 |
| Class G Copper Flex Conductor Size (kcmil) | 350 |
| Class H Copper Flex Conductor Size (kcmil) | 350 |
| Class I Copper Flex Conductor Size (kcmil) | 350 |
| Class K Copper Flex Conductor Size (kcmil) | 350 |
| Class M Copper Flex Conductor Size (kcmil) | 350 |
| DLO Copper Flex Conductor Size (kcmil) | 373.7 |
| Barrel Length (In.) | 1.29 |
| Barrel Length (mm) | 32.8 |
| Tongue Width (In.) | 1.54 |
| UPC | 07498343589 |
Panduit - LCAX350-38H-6 - Environmental Information
| RoHS Status | ROHS3 Compliant |
|---|---|
| Moisture Sensitivity Level (MSL) | Not Applicable |
| ECCN | EAR99 |
| HTSUS | 8536.90.4000 |
Panduit - LCAX350-38H-6 - Videos
| Panduit LCAX350-38H-6 Video 1 | Click to View |
|---|---|
| Panduit LCAX350-38H-6 Video 2 | Click to View |
