Brand: Panduit
|
SKU:
LCAX4/0-34-X
Panduit LCAX4/0-34-X | CuLug, 4/0AWG, 3/4StudPKG10
Regular price
$17.14
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit LCAX4/0-34-X | CuLug, 4/0AWG, 3/4StudPKG10
Regular price
$17.14
Unit price
Description
Description
Panduit LCAX4/0-34-X | CuLug, 4/0AWG, 3/4StudPKG10
One-hole, flex lug, 4/0 AWG wire, 3/4 stud hole.
Specifications
Specifications
Panduit - LCAX4/0-34-X - Specifications
| Product Type | Compression Lug |
|---|---|
| Base Material | Copper |
| Number of Stud Holes | 1 |
| Barrel Type | Standard |
| Barrel Entry | Beveled |
| Tongue Type | Standard |
| Tongue Angle | Straight |
| Finish/Coating | Tin-Plated |
| Stud Hole Size (In.) | 3/4 |
| Stud Hole Size (mm) | 19.1 |
| Stud Hole Spacing (mm) | 0 |
| Copper Code Conductor Size (AWG) | 4/0 |
| Class G Copper Flex Conductor Size (AWG) | 4/0 |
| Class H Copper Flex Conductor Size (AWG) | 4/0 |
| Class I Copper Flex Conductor Size (AWG) | 4/0 |
| Class K Copper Flex Conductor Size (AWG) | 4/0 |
| Class M Copper Flex Conductor Size (AWG) | 4/0 |
| DLO Copper Flex Conductor Size (AWG) | 4/0 |
| Barrel Length (In.) | 1.03 |
| Barrel Length (mm) | 26.2 |
| Tongue Width (In.) | 1.19 |
| Tongue Width (mm) | 30.2 |
| Tongue Thickness (In.) | 0.16 |
| Tongue Thickness (mm) | 4.1 |
| Overall Length (In.) | 3.04 |
| Overall Length (mm) | 77.2 |
| Standards Met | C22.2 No. 65-13, 486A-486B File #E52164, ABS approved |
| CSA Temperature Rating (°C) | 90 |
Panduit - LCAX4/0-34-X - Package Information
| UPC | 07498344766 |
|---|---|
| Std. Pkg. Qty. | 10 |
| Std. Pkg. Volume (cf) | 0.0328 |
| Std. Ctn. Qty. | 0 |
| Std. Ctn. Volume (cf) | 0.0000 |
