Panduit LCAX500-12-6 | Copper Compression Lug, 1 Hole, 500 kcmil
Regular price
$196.73
Unit price
Brand: Panduit
|
SKU:
DRC-005493
Regular price
$196.73
Unit price
Description
Description
Panduit LCAX500-12-6 | Copper Compression Lug, 1 Hole, 500 kcmil
The LCAX500-12-6 Tin-Plated Copper Compression Lug, one-hole, standard barrel, has color-coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection. An inspection window aids to visually assure full conductor insertion, and the tin-plate material helps to inhibit corrosion. UL Listed and CSA Certified to 35 KV and temperature rated to 90°C.
Specifications
Specifications
Panduit - LCAX500-12-6 - Product Categories
- Wire Termination
- Mechanical & Compression Lugs & Splices
Panduit - LCAX500-12-6 - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | LCAX500-12-6 |
| Item Description | Pan-Lug LCAX500-12-6 Comp Lug, 500 kcmil, Flex, Tin Plt Copper, One 1/2" Stud |
| Inside Diameter (In.) | 1.03 |
| Inside Diameter (mm) | 26.16 |
| Outer Diameter (In.) | 1.3 |
| Outer Diameter (mm) | 33.02 |
| Product Type | Compression Lug |
| Lug Type | 1 Stud Hole Lug |
| Base Material | Copper |
| Class G Copper Flex Conductor Size (kcmil) | 500 |
| Class H Copper Flex Conductor Size (kcmil) | 500 |
| Class I Copper Flex Conductor Size (kcmil) | 500 |
| Class K Copper Flex Conductor Size (kcmil) | 500 |
| Class M Copper Flex Conductor Size (kcmil) | 500 |
| DLO Copper Flex Conductor Size (kcmil) | 535.3 |
| Sub Brand | Pan-Lug |
| Stud Hole Size (In.) | 1/2 |
| Stud Hole Size (mm) | 12.7 |
| Barrel Type | Standard Barrel with Inspection Window |
| Barrel Length (In.) | 1.48 |
| Barrel Length (mm) | 37.6 |
| Tongue Type | Standard |
| Tongue Width (In.) | 1.89 |
| Tongue Width (mm) | 48 |
| Tongue Angle | Straight |
| Tongue Thickness (In.) | 0.26 |
| Tongue Thickness (mm) | 6.6 |
| Overall Length (In.) | 3.64 |
| Overall Length (mm) | 92.5 |
| Finish/Coating | Tin-Plated |
| Standards Met | UL listed to 486A-486B File #E52164 and CSA certified C22.2 No. 65-13 |
| CSA Temperature Rating (°C) | 90 |
| UL Temperature Rating (°C) | 90 |
| Maximum Voltage (kV) | 35 |
| Color Code | Pink |
| Panduit Die Index Number | P99 |
| Burndy Die Index Number | L99 |
| T & B Die Index Number | 99H |
| Wire Strip Length (In.) | 1-9/16 |
| Wire Strip Length (mm) | 39.6 |
| Part Features | Tin plated to inhibit corrosion,color coded barrel,inspection window, beveled wire entry. |
Brand Name - LCAX500-12-6 - Package Information
| UPC | 07498343603 |
|---|---|
| Standard Package Quantity | 6 |
| Standard Package Volume (cf) | 0.0528 |
| Standard Ctn. Quantity | 0 |
| Standard Ctn. Volume (cf) | 0.0000 |
Brand Name - LCAX500-12-6 - Videos
| Video URL 1 | Click to View |
|---|---|
| Video URL 2 | Click to View |
| Video URL 3 | Click to View |
