Panduit LCBH4-38-L | Pan-Lug Tin-Plated Copper Compression Connecto...
Regular price
$7.59
Unit price
Brand: Panduit
|
SKU:
PAN-LCBH4-38-L
Regular price
$7.59
Unit price
Description
Description
Panduit LCBH4-38-L | Pan-Lug Tin-Plated Copper Compression Connectors - Lugs
One-hole, long barrel lug with corona relief taper, #4 AWG wire, 3/8 stud hole.
Panduit LCBH4-38-L | LUG | ONE HOLE 4 AWG CORONA RELIEF
Specifications
Specifications
Panduit - LCBH4-38-L - Product Categories
- Wire Termination
- Mechanical & Compression Lugs & Splices
Panduit - LCBH4-38-L - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | LCBH4-38-L |
| Item Description | Pan-Lug Tin-Plated Copper Compression Connectors - Lugs |
| Copper Conductor Size (AWG) | #4 |
| Copper Conductor Size (kcmil) | 42 |
| Product Type | Tin-Plated Copper Compression Connectors - Lugs |
| Sub Brand | Pan-Lug |
| Stud Hole Size (In.) | 42.95 |
| Stud Hole Size (mm) | 9.5 |
| Barrel Type | Long Barrel Length without Inspection Window |
| Barrel Length (In.) | 1.05 |
| Barrel Length (mm) | 26.7 |
| Tongue Type | Standard |
| Tongue Width (In.) | 0.62 |
| Tongue Width (mm) | 15.7 |
| Tongue Angle | Straight |
| Tongue Thickness (In.) | 0.07 |
| Tongue Thickness (mm) | 1.8 |
| Overall Length (In.) | 2.16 |
| Overall Length (mm) | 54.9 |
| Standards Met | C22.2 No. 65-13, 486A-486B File #E52164 |
| Color Code | Gray |
| Panduit Die Index Number | P29 |
| Burndy Die Index Number | 8 |
| Wire Strip Length (In.) | 1.13 |
| Wire Strip Length (mm) | 28.6 |
| Part Features | Tin plated to inhibit corrosion,color coded barrel. |
Panduit - LCBH4-38-L - Package Information
| UPC | 07498390183 |
|---|---|
| Standard Package Quantity | 50 |
| Standard Package Volume (cf) | 0.0305 |
| Standard Ctn. Quantity | 0 |
| Standard Ctn. Volume (cf) | 0.0000 |
