Brand: Panduit
|
SKU:
DRC-007861
Panduit LCBX4/0-12-X | Pan-Lug LCBX4/0-12-X Comp. Lug, 4/0, Long Flex, Tin Plt Cu, Strt, One .5", PK10
Regular price
$122.06
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit LCBX4/0-12-X | Pan-Lug LCBX4/0-12-X Comp. Lug, 4/0, Long Fl...
Regular price
$122.06
Unit price
Description
Description
Panduit LCBX4/0-12-X | Pan-Lug LCBX4/0-12-X Comp. Lug, 4/0, Long Flex, Tin Plt Cu, Strt, One .5", PK10
One-hole, flex lug, long barrel, 4/0 AWG, 1/2 stud hole.
Specifications
Specifications
Panduit - LCBX4/0-12-X - Product Categories
- Wire Termination
- Mechanical & Compression Lugs & Splices
Panduit - LCBX4/0-12-X - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | LCBX4/0-12-X |
| Item Description | Pan-Lug LCBX4/0-12-X Comp. Lug, 4/0, Long Flex, Tin Plt Cu, Strt, One .5", PK10 |
| Product Type | Compression Lug |
| Base Material | Copper |
| Class G Copper Flex Conductor Size (AWG) | 4/0 |
| Class H Copper Flex Conductor Size (AWG) | 4/0 |
| Class I Copper Flex Conductor Size (AWG) | 4/0 |
| Class K Copper Flex Conductor Size (AWG) | 4/0 |
| Class M Copper Flex Conductor Size (AWG) | 4/0 |
| Copper Code Conductor Size (AWG) | 4/0 |
| DLO Copper Flex Conductor Size (AWG) | 4/0 |
| Sub Brand | Pan-Lug |
| Stud Hole Size (In.) | 1/2 |
| Stud Hole Size (mm) | 12.7 |
| Barrel Type | Long Barrel Length with Inspection Window |
| Barrel Length (In.) | 2.24 |
| Barrel Length (mm) | 56.9 |
| Tongue Type | Standard |
| Tongue Width (In.) | 1.19 |
| Tongue Width (mm) | 30.2 |
| Tongue Angle | Straight |
| Tongue Thickness (In.) | 0.16 |
| Tongue Thickness (mm) | 4.1 |
| Overall Length (In.) | 3.85 |
| Overall Length (mm) | 97.8 |
| Finish/Coating | Tin-Plated |
| Standards Met | CSA certified C22.2 No. 65-13, UL listed 486A-486B File #E52164 |
| UL Temperature Rating (°C) | 90 |
| Maximum Voltage (kV) | 35 |
| Color Code | Purple |
| Panduit Die Index Number | P54 |
| Burndy Die Index Number | 15 |
| T & B Die Index Number | 15 |
| Wire Strip Length (In.) | 2 5/16 |
| Wire Strip Length (mm) | 59 |
| Part Features | Tin plated to inhibit corrosion,color coded barrel,inspection window. |
Brand Name - LCBX4/0-12-X - Package Information
| UPC | 07498343730 |
|---|---|
| Standard Package Quantity | 10 |
| Standard Package Volume (cf) | 0.0296 |
| Standard Ctn. Quantity | 0 |
| Standard Ctn. Volume (cf) | 0.0000 |
Brand Name - LCBX4/0-12-X - Videos
| Video URL 1 | Click to View |
|---|---|
| Video URL 2 | Click to View |
