Description
Description
Panduit Pan-Lug Compression Lug, 2-Hole, Series: LCC-W, Copper Conductor, 500 kcmil Conductor, Die Code: P87, 35 kV, 1/2 in Stud, Straight Tongue, 1.54 in W x 0.22 in THK Tongue, 6.12 in Overall Length, Long With Inspection Window Barrel, 0.84 in ID x 1.06 in OD x 2.5 in L Barrel, 2-9/16 in L Wire Strip, 1-3/4 in Stud Hole Spacing, 90 deg C, 2-9/16 in Mounting Hole, Tin Plated Copper, Brown
Features + Benefits
- Long barrel maximizes number of crimps and provides premium wire pull-out strength and electrical performance
- Inspection window to visually assure full conductor insertion
- Color-coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection
- Tin-plated to inhibit corrosion
- For use with stranded copper conductors
Panduit LCC500-12W-6 | Tin-Plated Copper Compression Connectors - Lugs | UPC - 07498379851 Key Specs
| Inside Diameter (In.) | 0.84 |
| Inside Diameter (mm) | 21.33 |
| Outer Diameter (In.) | 1.06 |
| Outer Diameter (mm) | 26.92 |
| Product Type | Tin-Plated Copper Compression Connectors - Lugs |
| Lug Type | 2 Stud Hole Lug |
| Base Material | Copper |
| Copper Code Conductor Size (kcmil) | 500 |
| Sub Brand | Pan-Lug |
| Stud Hole Size (In.) | 1/2 |
| Stud Hole Size (mm) | 12.7 |
| Stud Hole Spacing (In.) | 1.75 |
| Stud Hole Spacing (mm) | 44.5 |
| Barrel Type | Long Barrel with Inspection Window |
| Barrel Length (In.) | 2.5 |
| Barrel Length (mm) | 63.5 |
| Tongue Type | Standard |
| Tongue Width (In.) | 1.54 |
| Tongue Width (mm) | 39.1 |
| Tongue Angle | Straight |
Panduit LCC500-12W-6 | Tin-Plated Copper Compression Connectors - Lugs | UPC - 07498379851 Data Sheets
| Part Drawings | Part Drawing - PDF - LCC500-12W-6 | Download and View |
| Catalog Cut Sheets | LCC-W | Download and View |
| Selection Guides | Power Connector Tool and Die Selection Guides | Download and View |
