Panduit LCCF2-38D-E | Compression Connectors - Lugs | UPC - 0749837...
Regular price
$12.16
Unit price
Brand: Panduit
|
SKU:
LCCF2-38D-E
Regular price
$12.16
Unit price
Description
Description
Panduit Pan-Lug Compression Lug, 2-Hole, Series: LCCF, Copper Conductor, 2 AWG Class K, M and DLO Conductor, Die Code: P33, 35 kV, 3/8 in Stud, Straight Tongue, 0.7 in W x 0.11 in THK Tongue, 3.57 in Overall Length, Flared/Long without Inspection Window Barrel, 0.36 in ID x 0.056 in OD x 1.36 in L Barrel, 1-7/16 in L Wire Strip, Tin Plated, 90 deg C, 1-7/16 in Mounting Hole, Copper, Brown
Features + Benefits
- Can be used with flex conductor class K, M and diesel locomotive
- Long barrel maximizes the number of crimps and provides premium wire pull-out strength and electrical performance
- Flared entry prevents bent back strands when inserting fine strand conductor into barrel
- Color coded barrels marked with Panduit die index numbers for proper crimp die selection
- Enclosed barrel prevents corrosive material from entering barrel when used in harsh environments
- Tin plated to inhibit corrosion
- For Use with flexible and extra-flexible copper conductors
Panduit LCCF2-38D-E | Compression Connectors - Lugs | UPC - 07498375299 Key Specs
| Product Type | Compression Connectors - Lugs |
| Sub Brand | Pan-Lug |
| Stud Hole Size (In.) | 42.95 |
| Stud Hole Size (mm) | 9.5 |
| Stud Hole Spacing (In.) | 1 |
| Stud Hole Spacing (mm) | 25.4 |
| Barrel Type | Long Barrel Length without Inspection Window |
| Barrel Length (In.) | 1.36 |
| Barrel Length (mm) | 34.5 |
| Tongue Type | Standard |
| Tongue Width (In.) | 0.7 |
| Tongue Width (mm) | 17.8 |
| Tongue Thickness (In.) | 0.11 |
| Tongue Thickness (mm) | 2.8 |
| Overall Length (In.) | 3.57 |
| Overall Length (mm) | 90.7 |
| Color Code | Brown |
| Panduit Die Index Number | P33 |
| Wire Strip Length (In.) | 1.44 |
| Wire Strip Length (mm) | 36.5 |
Panduit LCCF2-38D-E | Compression Connectors - Lugs | UPC - 07498375299 Data Sheets
| Catalog Cut Sheets | Catalog Cut Sheet - LCCF8-14A-L Product Page | Download and View |
| Part Drawings | Part Drawing - PDF - LCCF2-38D-E | Download and View |
Panduit LCCF2-38D-E | Compression Connectors - Lugs | UPC - 07498375299 Environmental Information
| Panduit's RoHS Statement | Download and View |
