Panduit Compression Lug Connector, 2-Hole, Series: LCCX, Extra-Flexible/Flexible/Stranded Copper Conductor, 250 kcmil, 262.6 kcmil Conductor, Die Code: P62, 35 kV, 3/8 in Stud, Standard/Straight Tongue, 1.28 in W x 0.17 in THK Tongue, 4.59 in Overall Length, Long/Standard Barrel, 0.7 in ID x 0.88 in OD x 2.24 in L Barrel, Specifications: 1 in Stud Hole Spacing, 2.31 in L Wire Strip, Tin Plated, 90 deg C, 2.31 in Mounting Hole, Copper, Yellow
Features + Benefits
- Can be used with code conductor and flex conductor class G, H, I, K, M and diesel locomotive
- Long barrel maximizes number of crimps and provides premium wire pull-out strength and electrical performance
- Generously beveled wire entry prevents bent back strands when inserting conductor into barrel
- Color coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection
- Inspection window to visually assure full conductor insertion
- Tin plated to inhibit corrosion
- For use with flexible, extra-flexible and code stranded copper conductors
Panduit LCCX250-38D-X | Compression Connectors - Lugs | UPC - 07498342609 Key Specs
| Product Type | Compression Connectors - Lugs |
| Sub Brand | Pan-Lug |
| Stud Hole Size (In.) | 42.95 |
| Stud Hole Size (mm) | 9.5 |
| Stud Hole Spacing (In.) | 1 |
| Stud Hole Spacing (mm) | 25.4 |
| Barrel Type | Long Barrel Length with Inspection Window |
| Barrel Length (In.) | 2.24 |
| Barrel Length (mm) | 56.9 |
| Tongue Type | Standard |
| Tongue Width (In.) | 1.28 |
| Tongue Width (mm) | 32.5 |
| Tongue Thickness (In.) | 0.17 |
| Tongue Thickness (mm) | 4.3 |
| Overall Length (In.) | 4.59 |
| Overall Length (mm) | 116.6 |
| Color Code | Yellow |
| Panduit Die Index Number | P62 |
| Burndy Die Index Number | 16 |
| Wire Strip Length (In.) | 2.31 |
