Panduit LCCX350-38D-6 | Compression Connectors - Lugs | UPC - 07498...
Description
Description
Panduit Compression Lug Connector, 2-Hole, Series: LCCX, Extra-Flexible/Flexible/Stranded Copper Conductor, 350 kcmil, 373.7 kcmil Conductor, Die Code: P76, 35 kV, 3/8 in Stud, Standard/Straight Tongue, 1.54 in W x 0.22 in THK Tongue, 4.95 in Overall Length, Long/Standard Barrel, 0.84 in ID x 1.06 in OD x 2.5 in L Barrel, Specifications: 1 in Stud Hole Spacing, 2-9/16 in L Wire Strip, Tin Plated, 90 deg C, 2.56 in Mounting Hole, Copper, Blue
Features + Benefits
- Can be used with code conductor and flex conductor class G, H, I, K, M and diesel locomotive
- Long barrel maximizes number of crimps and provides premium wire pull-out strength and electrical performance
- Generously beveled wire entry prevents bent back strands when inserting conductor into barrel
- Color coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection
- Inspection window to visually assure full conductor insertion
- Tin plated to inhibit corrosion
- For use with flexible, extra-flexible and code stranded copper conductors
Panduit LCCX350-38D-6 | Compression Connectors - Lugs | UPC - 07498342616 Key Specs
| Product Type | Compression Connectors - Lugs |
| Sub Brand | Pan-Lug |
| Stud Hole Size (In.) | 42.95 |
| Stud Hole Size (mm) | 9.5 |
| Stud Hole Spacing (In.) | 1 |
| Stud Hole Spacing (mm) | 25.4 |
| Barrel Type | Long Barrel Length with Inspection Window |
| Barrel Length (In.) | 2.5 |
| Barrel Length (mm) | 63.5 |
| Tongue Type | Standard |
| Tongue Width (In.) | 1.54 |
| Tongue Width (mm) | 39.1 |
| Tongue Thickness (In.) | 0.22 |
| Tongue Thickness (mm) | 5.6 |
| Overall Length (In.) | 4.95 |
| Overall Length (mm) | 125.7 |
| Color Code | Blue |
| Panduit Die Index Number | P76 |
| Burndy Die Index Number | 19 |
| Wire Strip Length (In.) | 2.56 |
Panduit LCCX350-38D-6 | Compression Connectors - Lugs | UPC - 07498342616 Data Sheets
| Catalog Cut Sheets | Flex Conductor, Two-Hole, Long Barrel with Window Lug | Download and View |
| Part Drawings | Part Drawing - PDF - LCCX350-38D-6 | Download and View |
| Selection Guides | Power Connector Tool and Die Selection Guides | Download and View |
Panduit LCCX350-38D-6 | Compression Connectors - Lugs | UPC - 07498342616 Environmental Information
| Panduit's RoHS Statement | Download and View |
