Panduit LCD1-14A-E | Pan-Lug Comp. Lug, Tin Plt Copper, Two 0.25" Stud, PK20
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit LCD1-14A-E | Pan-Lug Comp. Lug, Tin Plt Copper, Two 0.25&qu...
Description
Description
Two holes for added stability and a straight tongue for easy installation in electrical applications, our compression lug ensure reliable and secure electrical connections.
Two-hole, standard barrel lug with window, #1 AWG wire, 1/4 stud hole, .63 hole spacing.
Panduit Pan-Lug Compression Lug, 2-Hole, Series: LCD, Copper Conductor, 1 AWG Conductor, Die Code: P37, 35 kV, 1/4 in Stud, Straight Tongue, 0.7 in W x 0.11 in THK Tongue, 2.42 in Overall Length, Standard With Inspection Window Barrel, 0.36 in ID x 0.47 in OD x 0.88 in L Barrel, 15/16 in L Wire Strip, 5/8 in Stud Hole Spacing, 90 deg C, 15/16 in Mounting Hole, Tin Plated Copper, Green
Panduit - LCD1-14A-E - Features
- Color-coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection
- Inspection window to visually assure full conductor insertion
- Tin-plated to inhibit corrosion
- For use with stranded copper conductors
- Color-coded barrels marked with PANDUIT and specified competitor die index numbers for proper crimp die selection
- Inspection window to visually assure full conductor insertion
- Tin-plated to inhibit corrosion
- UL Listed and CSA Certified to 35 KV and teperature rated to 90C when crimped with PANDUIT and specified competitor crimping tools and dies
- UL Listed and CSA Certified for wide wire range-taking capability when crimped with PANDUIT(TM) Uni-Die(TM) Dieless Crimping Tools
- Tested by Telcordia - meets NEBS Level 3
- American Bureau of Shipping Approved
- Available with NEMA hole sizes and spacing
Specifications
Specifications
Panduit - LCD1-14A-E - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | LCD1-14A-E |
| Barrel | Standard |
| Bolt Hole | 1/4 Inch |
| Gauge | 1 Awg |
| Holes | 2 Hole |
| Inspection Hole | Yes |
| Lug Material | Copper |
| Type | Standard Compression |
| UNSPSC Code | 39121400 |
| Product Type | Compression Lug |
| Base Material | Copper |
| Number of Stud Holes | 2 |
| Barrel Type | Standard |
| Barrel Entry | Beveled |
| Tongue Type | Standard |
| Tongue Angle | Straight |
| Inspection Window | Yes |
| Finish/Coating | Tin-Plated |
| Stud Hole Size (In.) | 1/4 |
| Stud Hole Size (mm) | 6.4 |
| Stud Hole Spacing (In.) | 0.63 |
| Stud Hole Spacing (mm) | 16 |
| Copper Code Conductor Size (AWG) | 1 |
| Barrel Length (In.) | 0.88 |
| Barrel Length (mm) | 22.4 |
| Tongue Width (In.) | 0.75 |
| Tongue Width (mm) | 19.1 |
| Tongue Thickness (In.) | 0.11 |
| Tongue Thickness (mm) | 2.8 |
| Overall Length (In.) | 2.42 |
| UPC | 07498338293 |
