Brand: Panduit
|
SKU:
LCD250-12-X
Panduit LCD250-12-X | Tin-Plated Copper Compression Connectors - Lugs | UPC - 07498390098
Regular price
$17.14
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit LCD250-12-X | Tin-Plated Copper Compression Connectors - Lu...
Regular price
$17.14
Unit price
Description
Description
Panduit Pan-Lug Compression Lug, 2-Hole, Series: LCD, Copper Conductor, 250 kcmil Conductor, Die Code: P62, 35 kV, 1/2 in Stud, Standard/Straight Tongue, 1.17 in W x 0.14 in THK Tongue, 4.68 in Overall Length, Standard/Inspection Window Barrel, 0.63 in ID x 0.77 in OD x 1.25 in L Barrel, Specifications: 1-5/16 in L Wire Strip, 1-3/4 in Stud Hole Spacing, Tin Plated, 90 deg C, 1-5/16 in Mounting Hole, Copper, Yellow
Features + Benefits
- Color coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection
- Inspection window to visually assure full conductor insertion
- Tin plated to inhibit corrosion
- For use with stranded copper conductors
Panduit LCD250-12-X | Tin-Plated Copper Compression Connectors - Lugs | UPC - 07498390098 Key Specs
| Copper Conductor Size (kcmil) | 250 |
| Product Type | Tin-Plated Copper Compression Connectors - Lugs |
| Sub Brand | Pan-Lug |
| Stud Hole Size (In.) | 42.767 |
| Stud Hole Size (mm) | 12.7 |
| Stud Hole Spacing (In.) | 1.75 |
| Stud Hole Spacing (mm) | 44.5 |
| Barrel Type | Standard Barrel Length with Inspection Window |
| Barrel Length (In.) | 1.25 |
| Barrel Length (mm) | 31.8 |
| Tongue Type | Standard |
| Tongue Width (In.) | 1.17 |
| Tongue Width (mm) | 29.7 |
| Tongue Thickness (In.) | 0.14 |
| Tongue Thickness (mm) | 3.6 |
| Overall Length (In.) | 4.68 |
| Overall Length (mm) | 118.9 |
| Color Code | Yellow |
| Panduit Die Index Number | P62 |
| Burndy Die Index Number | 16 |
Panduit LCD250-12-X | Tin-Plated Copper Compression Connectors - Lugs | UPC - 07498390098 Data Sheets
| Catalog Cut Sheets | Catalog Cut Sheet - LCD10-10A-L Product Page | Download and View |
| Part Drawings | Part Drawing - PDF - LCD250-12-X | Download and View |
| Selection Guides | Power Connector Tool and Die Selection Guides | Download and View |
Panduit LCD250-12-X | Tin-Plated Copper Compression Connectors - Lugs | UPC - 07498390098 Environmental Information
| Panduit's RoHS Statement | Download and View |
