Brand: Panduit
|
SKU:
LCD350-12E-X
Panduit LCD350-12E-X | Tin-Plated Copper Compression Connectors - Lugs | UPC - 07498371962
Regular price
$19.65
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit LCD350-12E-X | Tin-Plated Copper Compression Connectors - L...
Regular price
$19.65
Unit price
Description
Description
Panduit Compression Lug, 2-Hole, Series: LCD, Stranded Copper Conductor, 350 kcmil Conductor, Die Code: P71, 35 kV, 1/2 in Stud, Standard/Straight Tongue, 1.28 in W x 0.17 in THK Tongue, 4.33 in Overall Length, Standard/Inspection Window Barrel, 0.7 in ID x 0.88 in OD x 1.44 in L Barrel, 1-1/2 in L Wire Strip, 1-1/4 in Stud Hole Spacing, Tin Plated, 90 deg C, 1-1/2 in Mounting Hole, Copper, Red
Features + Benefits
- Color coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection
- Inspection window to visually assure full conductor insertion
- Tin plated to inhibit corrosion
- For use with stranded copper conductors
Panduit LCD350-12E-X | Tin-Plated Copper Compression Connectors - Lugs | UPC - 07498371962 Key Specs
| Copper Conductor Size (kcmil) | 350 |
| Product Type | Tin-Plated Copper Compression Connectors - Lugs |
| Sub Brand | Pan-Lug |
| Stud Hole Size (In.) | 42.767 |
| Stud Hole Size (mm) | 12.7 |
| Stud Hole Spacing (In.) | 1.25 |
| Stud Hole Spacing (mm) | 31.8 |
| Barrel Type | Standard Barrel Length with Inspection Window |
| Barrel Length (In.) | 1.44 |
| Barrel Length (mm) | 36.6 |
| Tongue Type | Standard |
| Tongue Width (In.) | 1.28 |
| Tongue Width (mm) | 32.5 |
| Tongue Thickness (In.) | 0.17 |
| Tongue Thickness (mm) | 4.3 |
| Overall Length (In.) | 4.33 |
| Overall Length (mm) | 110 |
| Color Code | Red |
| Panduit Die Index Number | P71 |
| Burndy Die Index Number | 18 |
Panduit LCD350-12E-X | Tin-Plated Copper Compression Connectors - Lugs | UPC - 07498371962 Data Sheets
| Selection Guides | Selection Guide - SA-PCCR02 Tool Chart Guide WEB 4-19-10 | Download and View |
| Catalog Cut Sheets | Catalog Cut Sheet - LCD10-10A-L Product Page | Download and View |
| Part Drawings | Part Drawing - PDF - LCD350-12E-X | Download and View |
Panduit LCD350-12E-X | Tin-Plated Copper Compression Connectors - Lugs | UPC - 07498371962 Environmental Information
| Panduit's RoHS Statement | Download and View |
