Panduit LCDX1-56D-X | Compression Connectors - Lugs | UPC - 0749834...
Regular price
$7.59
Unit price
Brand: Panduit
|
SKU:
LCDX1-56D-X
Regular price
$7.59
Unit price
Description
Description
Panduit Pan-Lug Lug Compression Connector, 2-Hole, Series: LCDX, 1 AWG Conductor, Die Code: P37, 35 kV, 5/16 in Stud, Straight Tongue, 0.76 in W x 0.12 in THK Tongue, 2.72 in Overall Length, Standard Barrel, 0.66 in L Barrel, 90 deg C, 4.2828 in Mounting Hole, Tin Plated Copper, Green
Features + Benefits
Panduit LCDX1-56D-X | Compression Connectors - Lugs | UPC - 07498342738 Key Specs
| Product Type | Compression Connectors - Lugs |
| Sub Brand | Pan-Lug |
| Stud Hole Size (In.) | 42.491 |
| Stud Hole Size (mm) | 7.9 |
| Stud Hole Spacing (In.) | 1 |
| Stud Hole Spacing (mm) | 25.4 |
| Barrel Type | Standard Barrel Length with Inspection Window |
| Barrel Length (In.) | 0.66 |
| Barrel Length (mm) | 16.8 |
| Tongue Type | Standard |
| Tongue Width (In.) | 0.76 |
| Tongue Width (mm) | 19.3 |
| Tongue Thickness (In.) | 0.12 |
| Tongue Thickness (mm) | 3 |
| Overall Length (In.) | 2.72 |
| Overall Length (mm) | 69.1 |
| Color Code | Green |
| Panduit Die Index Number | P37 |
| Burndy Die Index Number | 11 |
| Wire Strip Length (In.) | 42,828 |
Panduit LCDX1-56D-X | Compression Connectors - Lugs | UPC - 07498342738 Data Sheets
| Catalog Cut Sheets | Catalog Cut Sheet - LCDX8-10A-L Product Page | Download and View |
| Part Drawings | Part Drawing - PDF - LCDX1-56D-X | Download and View |
| Selection Guides | Power Connector Tool and Die Selection Guides | Download and View |
