Panduit LCDX250-38D-X | Compression Connectors - Lugs | UPC - 07498...
Regular price
$21.09
Unit price
Brand: Panduit
|
SKU:
LCDX250-38D-X
Regular price
$21.09
Unit price
Description
Description
Panduit Pan-Lug Lug Compression Connector, 2-Hole, Series: LCDX, 250 kcmil, 262.6 kcmil Conductor, Die Code: P62, 35 kV, 3/8 in Stud, Straight Tongue, 1.28 in W x 0.17 in THK Tongue, 3.38 in Overall Length, Standard Barrel, 1.03 in L Barrel, 90 deg C, 1.06 in Mounting Hole, Tin Plated Copper, Yellow
Features + Benefits
Panduit LCDX250-38D-X | Compression Connectors - Lugs | UPC - 07498342398 Key Specs
| Product Type | Compression Connectors - Lugs |
| Sub Brand | Pan-Lug |
| Stud Hole Size (In.) | 42.95 |
| Stud Hole Size (mm) | 9.5 |
| Stud Hole Spacing (In.) | 1 |
| Stud Hole Spacing (mm) | 25.4 |
| Barrel Type | Standard Barrel Length with Inspection Window |
| Barrel Length (In.) | 1.03 |
| Barrel Length (mm) | 26.2 |
| Tongue Type | Standard |
| Tongue Width (In.) | 1.28 |
| Tongue Width (mm) | 32.5 |
| Tongue Thickness (In.) | 0.17 |
| Tongue Thickness (mm) | 4.3 |
| Overall Length (In.) | 3.38 |
| Overall Length (mm) | 85.9 |
| Color Code | Yellow |
| Panduit Die Index Number | P62 |
| Burndy Die Index Number | 16 |
| Wire Strip Length (In.) | 1.06 |
Panduit LCDX250-38D-X | Compression Connectors - Lugs | UPC - 07498342398 Data Sheets
| Part Drawings | Part Drawing - PDF - LCDX250-38D-X | Download and View |
| Selection Guides | Power Connector Tool and Die Selection Guides | Download and View |
| Installation Documents | Copper Compression Connector Installation | Download and View |
Panduit LCDX250-38D-X | Compression Connectors - Lugs | UPC - 07498342398 Environmental Information
| Panduit's RoHS Statement | Download and View |
