Panduit LCDX500-56D-6 | Compression Connectors - Lugs | UPC - 07498...
Regular price
$33.48
Unit price
Brand: Panduit
|
SKU:
LCDX500-56D-6
Regular price
$33.48
Unit price
Description
Description
Panduit Pan-Lug Lug Compression Connector, 2-Hole, Series: LCDX, 500 kcmil, 535.3 kcmil Conductor, Die Code: P99, 35 kV, 5/16 in Stud, Straight Tongue, 1.89 in W x 0.26 in THK Tongue, 4.05 in Overall Length, Standard Barrel, 1.48 in L Barrel, 90 deg C, 1.56 in Mounting Hole, Tin Plated Copper, Pink
Features + Benefits
Panduit LCDX500-56D-6 | Compression Connectors - Lugs | UPC - 07498345364 Key Specs
| Product Type | Compression Connectors - Lugs |
| Sub Brand | Pan-Lug |
| Stud Hole Size (In.) | 42.491 |
| Stud Hole Size (mm) | 7.9 |
| Stud Hole Spacing (In.) | 1 |
| Stud Hole Spacing (mm) | 25.4 |
| Barrel Type | Standard Barrel Length with Inspection Window |
| Barrel Length (In.) | 1.48 |
| Barrel Length (mm) | 37.6 |
| Tongue Type | Standard |
| Tongue Width (In.) | 1.89 |
| Tongue Width (mm) | 48 |
| Tongue Thickness (In.) | 0.26 |
| Tongue Thickness (mm) | 6.6 |
| Overall Length (In.) | 4.05 |
| Overall Length (mm) | 102.9 |
| Color Code | Pink |
| Panduit Die Index Number | P99 |
| Burndy Die Index Number | L99 |
| Wire Strip Length (In.) | 1.56 |
Panduit LCDX500-56D-6 | Compression Connectors - Lugs | UPC - 07498345364 Data Sheets
| Selection Guides | Selection Guide - SA-PCCR02 Tool Chart Guide WEB 4-19-10 | Download and View |
| Catalog Cut Sheets | Catalog Cut Sheet - LCDX8-10A-L Product Page | Download and View |
| Selection Guides | Power Connector Tool and Die Selection Guides | Download and View |
Panduit LCDX500-56D-6 | Compression Connectors - Lugs | UPC - 07498345364 Environmental Information
| Panduit's RoHS Statement | Download and View |
