Brand: Panduit
|
SKU:
LCDX750-38DH-3
Panduit LCDX750-38DH-3 | Compression Connectors - Lugs | UPC - 07498344989
Regular price
$78.58
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit LCDX750-38DH-3 | Compression Connectors - Lugs | UPC - 0749...
Regular price
$78.58
Unit price
Brand: Panduit
|
SKU:
LCDX750-38DH-3
Regular price
$78.58
Unit price
Shipping calculated at checkout.
Description
Description
Panduit Pan-Lug Lug Compression Connector, 2-Hole, Series: LCDX, 777.7 kcmil Conductor, Die Code: P115, 35 kV, 3/8 in Stud, 45 deg Tongue, 2.17 in W x 0.32 in THK Tongue, 4.21 in Overall Length, Standard Barrel, 1.66 in L Barrel, 90 deg C, 1-3/4 in Mounting Hole, Tin Plated Copper, Yellow
Features + Benefits
Panduit LCDX750-38DH-3 | Compression Connectors - Lugs | UPC - 07498344989 Key Specs
| Product Type | Compression Connectors - Lugs |
| Sub Brand | Pan-Lug |
| Stud Hole Size (In.) | 42.95 |
| Stud Hole Size (mm) | 9.5 |
| Stud Hole Spacing (In.) | 1 |
| Stud Hole Spacing (mm) | 25.4 |
| Barrel Type | Standard Barrel Length with Inspection Window |
| Barrel Length (In.) | 1.66 |
| Barrel Length (mm) | 42.2 |
| Tongue Type | Standard |
| Tongue Width (In.) | 2.17 |
| Tongue Width (mm) | 55.1 |
| Tongue Thickness (In.) | 0.32 |
| Tongue Thickness (mm) | 8.1 |
| Overall Length (In.) | 4.21 |
| Overall Length (mm) | 106.9 |
| Color Code | Yellow |
| Panduit Die Index Number | P115 |
| Burndy Die Index Number | L115 |
| Wire Strip Length (In.) | 1.75 |
Panduit LCDX750-38DH-3 | Compression Connectors - Lugs | UPC - 07498344989 Data Sheets
| Part Drawings | Part Drawing - PDF - LCDX750-38DH-3 | Download and View |
| Catalog Cut Sheets | Flex Conductor, Two-Hole, Standard Barrel 45° | Download and View |
| Selection Guides | Power Connector Tool and Die Selection Guides | Download and View |
Panduit LCDX750-38DH-3 | Compression Connectors - Lugs | UPC - 07498344989 Environmental Information
| Panduit's RoHS Statement | Download and View |
