Brand: Panduit
|
SKU:
283550-EA
Panduit MLT8S-CP | Pan-Steel MLT8S-CP Cable Tie, SS 304, Standard, 8" Dia., PK100
Regular price
$3.00
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit MLT8S-CP | Pan-Steel MLT8S-CP Cable Tie, SS 304, Standard, ...
Regular price
$3.00
Unit price
Description
Description
Panduit MLT8S-CP | Pan-Steel MLT8S-CP Cable Tie, SS 304, Standard, 8" Dia., PK100
The MLT8S-CP Pan-Steel 304 grade stainless steel cable tie speeds up installation with a patented, wide entry self-locking head that eases band threading and insertion. Unique locking ramp design and strengthening ribs allows the tie to lock into place at any length along the tie body with increased lock strength. Fully rounded edges ensure worker and bundle safety.
Panduit MLT8S-CP - CABLE TIE - 26.8" STAINLESS CABLE TIE
Specifications
Specifications
Panduit - MLT8S-CP - Product Categories
- Wire Routing, Management & Protection
- Cable Ties & Wire Ties
Panduit - MLT8S-CP - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | MLT8S-CP |
| Item Description | Pan-Steel MLT8S-CP Cable Tie, SS 304, Standard, 8" Dia., PK100 |
| Product Type | Stainless Steel Cable Ties |
| Sub Brand | Pan-Steel |
| Color | Metallic |
| Environment | Indoor/Outdoor |
| Material | Stainless Steel Type 304 |
| Resistance Properties | UV Resistant |
| Overall Length (In.) | 26.8 |
| Overall Length (mm) | 679 |
| Body Width (In.) | 0.18 |
| Body Width (mm) | 4.6 |
| Body Thickness (In.) | 0.01 |
| Body Thickness (mm) | 0.25 |
| Maximum Bundle Diameter (In.) | 8 |
| Maximum Bundle Diameter (mm) | 203 |
| Minimum Bundle Diameter (In.) | 0.5 |
| Minimum Bundle Diameter (mm) | 12.7 |
| Minimum Loop Tensile Strength (N) | 890 |
| Minimum Loop Tensile Strength (lb) | 200 |
| Maximum Operating Temperature (°C) | 538 |
| Maximum Operating Temperature (°F) | 1000 |
| Minimum Operating Temperature (°C) | -60 |
| Minimum Operating Temperature (°F) | -76 |
| Minimum Installation Temperature (°C) | -60 |
| Minimum Installation Temperature (°F) | -76 |
| Standards Met | UL E56854,CE,ABS,GL,SAE,BV,LR,DNV |
| Military Cross Reference Number | M23190/3-4 |
| For Use With | GS4MT-E, HTMT, PPTMT, ST2MT |
| Application | General |
Panduit - MLT8S-CP - Package Information
| UPC | 07498354407 |
|---|---|
| Standard Package Quantity | 100 |
| Standard Package Volume (cf) | 0.0422 |
| Standard Ctn. Quantity | 500 |
| Standard Ctn. Volume (cf) | 0.2108 |
Panduit - MLT8S-CP - Videos
| Video 1 | Click to View |
|---|---|
| Video 2 | Click to View |
