Panduit MS6W75T30-Q6 | Pan-Steel® Discrete Length Stainless Steel B...
Description
Description
Panduit Pan-Steel Cable Strap, Series: MS Series, 26.5 in Length, 3/4 in Width, 0.03 in Thickness, 6 in Bundle Dia, Fold Over, 2400 lb Tensile, -76 to 1000 deg F, 316 Stainless Steel, Natural
Secure your cables in harsh environments with our stainless steel buckle strap. Versatile design fits various cables, offering reliable protection against high short circuit fault currents.
The MS8W75T30-Q6 Discrete Length Stainless Steel Buckle Strap cable cleat is an effective option for protecting against high short circuit fault current requirements in harsh environments. The variable design is compatible with quad, trefoil, and multi core cables and certified to IEC61914:2015, for use up to 188kA peak fault current. The product features a low-profile fold-over buckle, 316L AISI Stainless Steel, 838mm length, 19mm width, 10656N tensile strength, and 203mm bundle capacity.
Panduit - MS6W75T30-Q6 - Features
- Applications: Corrosive Environment
Specifications
Specifications
Panduit - MS6W75T30-Q6 - Specifications
| UNSPSC Code | 39121703 |
|---|---|
| Technical Information | RoHS Compliant, UL E56854, UV Resistant |
| Product Type | Strapping |
| Application | Corrosive Environment |
| Color | Natural |
| Environment | Harsh/Indoor/Outdoor |
| For Use With | BT75SDT |
| Material | Stainless Steel Type 316 |
| Maximum Bundle Diameter (In.) | 6 |
| Maximum Bundle Diameter (mm) | 152 |
| Maximum Installation Temperature (°C) | 538 |
| Maximum Installation Temperature (°F) | 1000 |
| Minimum Installation Temperature (°C) | -60 |
| Minimum Installation Temperature (°F) | -76 |
| Maximum Operating Temperature (°C) | 538 |
| Maximum Operating Temperature (°F) | 1000 |
| Minimum Operating Temperature (°C) | -60 |
| Minimum Operating Temperature (°F) | -76 |
| Minimum Loop Tensile Strength (N) | 10656 |
| Minimum Loop Tensile Strength (lb) | 2400 |
| Overall Length (In.) | 25.9 |
| Overall Length (mm) | 658 |
| Overall Width (In.) | 0.75 |
| UPC | 07498358710 |
Panduit - MS6W75T30-Q6 - Package Information
| UPC | 07498358710 |
|---|---|
| Standard Packaging Quantity | 25 |
| Standard Packaging Volume (cf) | 0.2459 |
| Standard Ctn. Quantity | 0 |
| Standard Ctn. Volume (cf) | 0.0000 |
Panduit - MS6W75T30-Q6 - Videos
| Panduit MS6W75T30-Q6 Videos | Click to View |
|---|
