Panduit P110PC4IG4AY | Pan-Punch Patch Cord Assembly
Description
Description
Our patch cord assembly offers a user-friendly and efficient solution for connecting your network cables. Its innovative features and durable design ensure reliable performance.
The 110 punchdown system shall provide deep channels in each base that allow jacketed cable to be routed within 0.50 in of the point of wire termination. Each base shall have color-coded wire strips that assist in wire sorting and troubleshooting. Connecting blocks shall have test access through the housing, allowing testing of individual contacts without removing the wire. The jumper troughs shall have rounded edges that eliminate sharp bends in cable and help maintain Category 5E minimum bend radius.
Panduit Pan-Punch Patch Cord Assembly, U/UTP, Category: Cat 5e, 24 AWG Conductor, 110 Plug/RJ45 Pan-Plug T568A Boot Connector, 4 ft Cord, Green
Panduit - P110PC4IG4AY - Features
- 100% performance tested
- Robust construction
- Provides identification of performance level, length and quality control number for future traceability
- Patented tangle free latch on modular plugs
- Meets individual length requirements for greater system flexibility
- Jack module black plug
Specifications
Specifications
Panduit - P110PC4IG4AY - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | P110PC4IG4AY |
| Product Type | Patch Cord Assembly |
| Application | (1) Telecommunications closets and main distribution frames(2) Voice networks and data local area networks designed for use with unshielded twisted pair copper wire and cable(3) Jobs as small as 100-pair |
| Performance Level | Category 5e |
| Conductor Type | Stranded |
| Cable Construction | U/UTP |
| Patch Cord Type | Unshielded |
| Overall Length (ft.) | 4 |
| Sub Brand | Pan-Punch |
| Color | Green |
| Standards Met | Exceeds ANSI/TIA-568-C.2 Category 5e standard, meets IEC 60352-4 requirements, RoHS Compliant |
| IEC Variant | 60352-4 |
| Part Features | Deeper cable channel in the base, Rounded edges on jumper trough, Field terminable patch cord connector, Metal contact retention in connecting block, Legs are molded as part of the base, Base has TIP colors on wire strip and Connecting block has RING colors for wiring identification |
| UPC | 07498305746 |
Panduit - P110PC4IG4AY - Environmental Information
| RoHS Status | ROHS3 Compliant |
|---|---|
| Moisture Sensitivity Level (MSL) | Not Applicable |
| ECCN | OBSOLETE |
