Panduit P110PC4IG6BY | Patch Cord Assembly | UPC - 07498305756
Description
Description
The 110 punchdown system shall provide deep channels in each base that allow jacketed cable to be routed within 0.50 in of the point of wire termination. Each base shall have color-coded wire strips that assist in wire sorting and troubleshooting. Connecting blocks shall have test access through the housing, allowing testing of individual contacts without removing the wire. The jumper troughs shall have rounded edges that eliminate sharp bends in cable and help maintain Category 5E minimum bend radius.
Panduit Pan-Punch Patch Cord Assembly, U/UTP, Category: Cat 5e, 24 AWG Conductor, 110 Plug/RJ45 Pan-Plug T568A Boot Connector, 6 ft Cord, Green
Features + Benefits
- 100% performance tested
- Robust construction
- Provides identification of performance level, length and quality control number for future traceability
- Patented tangle free latch on modular plugs
- Meets individual length requirements for greater system flexibility
- Jack module black plug
Panduit P110PC4IG6BY Key Specs
| Application | Allow the design of secure, modular, end-to-end connectivity for communication and computing elements from the data center to the workstation |
| Note | P110PC4IG6AY replaces P110PC4IG6A |
| Product Type | Patch Cord Assembly |
| Performance Level | Category 5e |
| Conductor Type | Stranded |
| Cable Construction | U/UTP |
| Patch Cord Type | Unshielded |
| Plug Housing Material | Polycarbonate |
| Connector 1 Type | 4-Pair 110 Connector |
| Connector 2 Type | 4-Pair 110 Connector |
| Overall Length (ft.) | 6 |
| Sub Brand | Pan-Punch |
| Wiring Scheme | T568B |
| Color | International Gray |
| Standards Met | Exceeds all channel and component requirements of ANSI/TIA-568-C.2 Category 5e standard; Meets IEC 60352-4 requirements; CE Compliant; RoHS Compliant |
| IEC Variant | 60352-4 |
| Plug Type | 8 Position |
| Part Features | Deeper cable channel in the base, Rounded edges on jumper trough, Field terminable patch cord connector, Metal contact retention in connecting block, Legs are molded as part of the base, Base has TIP colors on wire strip and Connecting block has RING colors for wiring identification |
Panduit P110PC4IG6BY Data Sheets
| Specification Sheets | Specification Sheet - C-CMPTSGB16-ENG | Download and View |
| Catalogs | StrongHold Electrical/Network Supports and Fasteners: CMCB02--SA-2018-ENG | Download and View |
| Application Guides | Best Seller Products for Industrial Construction, MRO and OEM Application Guide ELCB33 | Download and View |
