Brand: Panduit | SKU: 501671

Panduit P18-8F-C | Pan-Term P18-8F-C Loose Piece Forks

Name: Panduit P18-8F-C | Pan-Term P18-8F-C Loose Piece Forks
Brand: Anixter
SKU: 501671
Price: 52.21 USD
Availability: InStock

$52.21

Shipping calculated at checkout.

Description

Fork Terminal, non-insulated, 22- 16 AWG, #8 stud size, standard package.

Brand Name	Panduit
Manufacturer Part Number	P18-8F-C
Item Description	Pan-Term P18-8F-C Loose Piece Forks
Fork Type	Standard
Insulation Material	Non-Insulated
Insulation Type	Non-Insulated
Maximum Copper Conductor Size (AWG SOL)	#16
Maximum Copper Conductor Size (AWG STR)	#16
Maximum Copper Conductor Size (AWG)	#16
Maximum Wire Size (AWG)	#16
Minimum Wire Size (AWG)	#22
Minimum Copper Conductor Size (AWG SOL)	#22
Minimum Copper Conductor Size (AWG STR)	#22
Minimum Copper Conductor Size (AWG)	#22
Maximum Metric Conductor Size (mm²)	1.5
Minimum Metric Conductor Size (mm²)	0.5
Stud Size	#8
Wire Strip Length (In.)	9/32
Wire Strip Length (mm)	7.1
Standards Met	UL Listed 587H E52164; CSA Certified LR31212
Maximum Voltage (V)	2000
Maximum Voltage (kV)	2
Base Material	Copper
Finish/Coating	Tin-Plated
Color Code	Metallic
Barrel Type	Standard
Barrel Length (In.)	0.27
Barrel Length (mm)	6.7
Maximum Operating Temperature (°C)	150
Maximum Operating Temperature (°F)	302
Seam Type	Brazed
Outer Diameter (In.)	0.14
Outer Diameter (mm)	3.6
Stud Hole Size (In.)	#8
Stud Hole Size (mm)	4
Inside Diameter (In.)	0.07
Inside Diameter (mm)	1.8
Overall Length (In.)	0.69
Overall Length (mm)	17.5
Overall Width (In.)	0.32
Overall Width (mm)	8.1
Tongue Length (In.)	0.43
Tongue Length (mm)	10.8
Sub Brand	Pan-Term
Tongue Thickness (In.)	0.03
Tongue Thickness (mm)	0.8
Tongue Width (In.)	0.32
Tongue Width (mm)	8.1
Packaging Type	Bottle
Product Type	Fork Terminal
