Panduit PCSH-B-CR | Pan-Steel PCSH-B-CR Cushion Sleeve, Reel, Neopr...
Description
Description
The PCSH-B-CR Custom Length Cushion Sleeving is designed for use with metal locking strap and buckle strap cable cleats to help protect in the event of a short circuit fault, minimizing disruption and damage to personnel and property. The cushion sleeving is compatible with light and heavy cross section ties or custom length banding systems, for use in harsh environments and applications. Features include C-shaped channel, black-colored neoprene material, 11.9mm width, and 100-foot reels.
Cushion sleeving used with heavy cross section ties or custom length banding system, "C" shaped channel design.
Panduit - PCSH-B-CR - Features
- Operating temperature range -40F - 200F (-40C - 93C)
- Supplied in 100 ft (30.5m) reels
- C shaped channel design available in types PCSS-B-CR and PCSH-B-CR cushion sleeve
- U shaped channel design available in type PCSSH-B-CR cushion sleeve
Specifications
Specifications
Panduit - PCSH-B-CR - Product Categories
- Wire Routing, Management & Protection
- Cable Tie Accessories
Panduit - PCSH-B-CR - Specifications
| Brand Name | Panduit |
|---|---|
| Manufacturer Part Number | PCSH-B-CR |
| Item Description | Pan-Steel PCSH-B-CR Cushion Sleeve, Reel, Neoprene, 100ft L, 0.47in W, RL1 |
| Application | General |
| Product Type | Cusion Sleeve |
| Color | Black |
| Environment | Indoor/Outdoor |
| Sub Brand | Pan-Steel |
| For Use With | MLTLH, MLTH |
| Material | Neoprene |
| Maximum Installation Temperature (°C) | 93 |
| Minimum Installation Temperature (°C) | -80 |
| Maximum Installation Temperature (°F) | 200 |
| Minimum Installation Temperature (°F) | -112 |
| Maximum Operating Temperature (°C) | 93 |
| Minimum Operating Temperature (°C) | -80 |
| Maximum Operating Temperature (°F) | 200 |
| Minimum Operating Temperature (°F) | -112 |
| Overall Height (In.) | 0.13 |
| Overall Height (mm) | 3.4 |
| Overall Length (In.) | 1200 |
| Overall Length (mm) | 30500 |
| Overall Width (In.) | 0.47 |
| Overall Width (mm) | 11.9 |
| Resistance Properties | Flammability Rating UL94 V-0 |
Panduit - PCSH-B-CR - Package Information
| UPC | 07498354431 |
|---|---|
| Standard Package Quantity | 1 |
| Standard Package Volume (cf) | 0.2681 |
| Standard Ctn. Quantity | 0 |
| Standard Ctn. Volume (cf) | 0.0000 |
Panduit - PCSH-B-CR - Videos
| Video 1 | Click to View |
|---|
