Panduit PFC6004BU-G | Copper Cable | UPC - 07498319514

The TX6 Cat 6 shielded F/UTP copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The conductors are twisted in pairs and separated by a cross divider. All four pairs are surrounded by an overall metallic foil shield within a PVC flame-retardant jacket. The blue, CM cable is supplied 305 meters (1,000 feet) to a reel.

---

Panduit PFC6004BU-G | Copper Cable | UPC - 07498319514 Key Specs

Note	Available in Asia Pacific and Latin America
Environment	Indoor
Performance Level	Category 6
Cable Construction	F/UTP
Flammability Rating	CM
Resistance Properties	Flame Retardant
Jacket Material	Polyvinyl Chloride (PVC)
Nominal Cable Outside Diameter (In.)	0.296
Nominal Cable Outside Diameter (mm)	7.5
Maximum Operating Temperature (°C)	75
Maximum Operating Temperature (°F)	167
Minimum Operating Temperature (°C)	-20
Minimum Operating Temperature (°F)	-4
Maximum Installation Temperature (°C)	50
Maximum Installation Temperature (°F)	122
Minimum Installation Temperature (°C)	0
Minimum Installation Temperature (°F)	32
Sub Brand	TX6000
