Panduit PFL6X04BU-CEG | Copper Cable, Cat 6A, 23 AWG, F/UTP, LSZH-3, Blue
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Panduit PFL6X04BU-CEG | Copper Cable, Cat 6A, 23 AWG, F/UTP, LSZH-3...
Description
Description
Category 6A cable shall be constructed of 23 AWG copper conductors with PE CM, CMR or LSZH insulation. The copper conductors shall be twisted in pairs and separated by an integrated pair separator. All four pairs shall be surrounded by an overall metallic foil shield within a low smoke zero halogen jacket. The TX6A 10Gig Shielded Copper Cable must be installed as part of a complete TX6A 10Gig Shielded Copper Cabling System to achieve 10GBASE-T certified performance.
Specifications
Specifications
Panduit - PFL6X04BU-CEG - Specifications
| Environment | Indoor |
|---|---|
| Performance Level | Category 6A |
| Cable Construction | F/UTP |
| Flammability Rating | LSZH-3 |
| Jacket Material | High-Density Polyethylene |
| Nominal Cable Outside Diameter (mm) | 7.3 |
| Maximum Operating Temperature (°F) | 167 |
| Minimum Operating Temperature (°F) | -4 |
| Bend Radius (mm) | 29.2 |
| Number of Pairs | 4 |
| Conductor Type | Solid |
| Conductor Material | Copper |
| Conductor Gauge (AWG) | 23 |
| Maximum Voltage (V) | 80 |
